Panasonic MINAS A6 Servo Motor 1kW 200V AC with 23-bit Encoder and IP67 Protection

Large Image : Panasonic MINAS A6 Servo Motor 1kW 200V AC with 23-bit Encoder and IP67 Protection

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Certification:	CE UL ROSH
Model Number:	MSMF102L1G6M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MINAS A6 Servo Motor 1kW 200V AC with 23-bit Encoder and IP67 Protection

Description

Condition:	Original Brand New	Warranty:	One Year
Series:	Eaton Crouse-Hinds Series	Shipping Way:	DHL FedEx Express
Application:	Automation Industries, Oil, Gas, Chemical Industries	Certificate:	CE ISO TUV
Highlight:	1KW Panasonic AC Servo Driver , Panasonic AC Servo Driver IP67 , MSMF102L1G6M

Panasonic MSMF102L1G6M Servo Motor

Product Overview

The Panasonic MSMF102L1G6M is a high-performance low-inertia AC servo motor from the MINAS A6 family, designed for demanding industrial automation applications requiring high speed and precise positioning. With a rated output of 1.0 kW (1000W) and 200V AC power supply, this motor delivers exceptional dynamic response.

Key Features:

1.0 kW Power Output with 200V AC power supply
Low Inertia Design for superior acceleration/deceleration
23-bit absolute/incremental encoder with 8,388,608 pulses/revolution
IP67 Protection Rating against dust and water jets
Wide speed range: 3000 r/min rated, 5000 r/min maximum
Robust torque output up to 9.55 N·m peak

Technical Specifications

Specification	Value
Part Number	MSMF102L1G6M
Rated Output	1000 W
Voltage	200 V
Rated Torque	3.18 N·m
Peak Torque	9.55 N·m
Rated Speed	3000 r/min
Max Speed	5000 r/min
Rotor Inertia	2.15 × 10⁻⁴ kg·m²
Encoder	23-bit Absolute/Incremental
Protection Class	IP67
Mass	3.6 kg

Permissible Load Specifications

Load Type	During Assembly	During Operation
Radial Load (P-direction)	980 N	490 N
Thrust Load (A-direction)	588 N	196 N
Thrust Load (B-direction)	686 N	196 N

Compatible Drivers

Part Number	Series	Type	Interface
MDDLN55NE	A6NE	RTEX Network (Basic)	RTEX
MDDLN55SE	A6SE	Position Control	Pulse Train
MDDLN55SG	A6SG	RS485/RS232 Communication	Pulse, Modbus
MDDLT55NF	A6NF	RTEX Network (Multi)	RTEX
MDDLT55SF	A6SF	Multifunction	Analog/Pulse, Modbus

Important Note: When using the rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder.

Typical Applications

High-Speed Pick-and-Place Systems

Industrial Robotics

CNC Machinery

Packaging Equipment

Automated Assembly Lines

Semiconductor Manufacturing

3C Manufacturing

High-Speed Automation
