Large Image : Panasonic MDDLT45SF MINAS A5 Series 1.0kW RTEX Servo Drive with 200V Input for High-Speed Motion Control

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDDLT45SF

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MDDLT45SF MINAS A5 Series 1.0kW RTEX Servo Drive with 200V Input for High-Speed Motion Control

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 1KW servo driver , AC servo motor driver , Panasonic servo driver with warranty

Panasonic MDDLT45SF MINAS A5 Series 1.0kW RTEX Servo Drive 200V

Product Overview

The Panasonic MDDLT45SF is a high-performance 1.0kW (1000W) AC Servo Driver engineered for advanced network-based motion control. As a specialized model in the MINAS A5 Series, it features a native RTEX (Realtime Express) interface—Panasonic's proprietary 100Mbps high-speed network. This allows for seamless, synchronized control of up to 32 axes with minimal wiring and maximum noise immunity.

Operating on a 200V-240V input, this D-Frame drive is built for precision and power. With a 2.0kHz speed frequency response and support for high-resolution encoders, the MDDLT45SF is the industry standard for high-speed pick-and-place, semiconductor equipment, and multi-axis robotics.

Technical Specifications

Feature	Specification
Model Number	MDDLT45SF
Series	MINAS A5 Series
Communication	RTEX (Realtime Express) 100Mbps
Rated Output	1.0 kW (1000 W)
Frame Size	D-Frame
Input Voltage	3-Phase 200V - 240V AC
Frequency Response	2.0 kHz (Industry Proven)
Encoder Support	20-bit Incremental / 17-bit Absolute
Safety Certification	STO (Safe Torque Off) Compliant

Key Benefits

High-Speed RTEX Synchronization

RTEX technology enables a 100Mbps communication speed with a command cycle of as little as 0.5ms. This makes the MDDLT45SF ideal for machines where multiple axes must move in perfect harmony, such as delta robots or complex CNC gantries.

Reduced Wiring & Noise Immunity

By using standard shielded twisted pair cables (Cat5e), the RTEX interface drastically reduces cabinet wiring complexity compared to traditional pulse/analog systems. This digital communication also provides superior resistance to electromagnetic interference (EMI).

High-Resolution 20-bit Precision

When paired with MINAS A5 motors, this drive handles 20-bit serial encoders (1.04 million pulses per revolution). This high resolution ensures smooth rotation at low speeds and incredibly accurate positioning, reducing mechanical stress and improving product quality.

Robust Vibration Suppression

The MDDLT45SF features advanced adaptive filters that automatically detect and suppress mechanical resonance. This "Real-time Auto-Gain Tuning" ensures stable operation even as mechanical loads or belt tensions change over time.

Primary Industrial Applications

Semiconductor Tools: High-speed die bonding, wafer handling, and inspection
Electronics Assembly: Multi-axis SMT placement and PCB testing equipment
Robotics: Synchronized control for 4-axis and 6-axis industrial robotic arms
Packaging Machinery: High-speed labeling and synchronized rotary filling axes
Printing Equipment: Precision tension and roller control for wide-format printing
