MCDLN35SG Panasonic 750W AC Servo Driver

Large Image : MCDLN35SG Panasonic 750W AC Servo Driver

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MCDLN35SG

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MCDLN35SG Panasonic 750W AC Servo Driver

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 750W servo driver , AC servo motor driver , 750W servo driver with warranty

MCDLN35SG Panasonic 750W AC Servo Driver

Product Overview

Part Number	MCDLN35SG
Product	Servo Driver
Series	A6SG series
Communication	RS485/RS232 Communication type (Pulse train only)
Safety Function	Without safety function
Family Name	MINAS A6

Key Features

Swifter, smarter and easier to use
Powered Up compact driver
MINAS A6S Series Servo Driver

Technical Specifications

Control Method	Position control
Frequency Response	3.2 kHz
Supply Voltage	Single/3-phase 200 V
Interface Type	Pulse, Modbus (RS485 /RS232)
Dimensions (W×H×D)	65 × 150 × 170 mm
Mass	1.6 kg
Frame	C-Frame

Basic Specifications

Power Input

Main circuit: Single/3-phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz

Control circuit: Single phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz

Encoder Feedback

23-bit (8388608 resolution) absolute encoder, 7-wire serial

Parallel I/O Connector

Control signal Input: General purpose 10 inputs

Control signal Output: General purpose 6 outputs

Analog signal Output: 2 outputs (Analog monitor)

Pulse signal Input: 2 inputs (Photo-coupler input, Line receiver input)

Pulse signal Output: 4 outputs (Line driver: 3 output, open collector: 1 output)

Communication Functions

USB: Interface to connect to computers for parameter setting or status monitoring

RS232: 1:1 communication

RS485: 1:n communication (max 31)

Modbus-RTU: 1:n communication

Additional Features

Regeneration: Built-in regenerative resistor (external resistor is also enabled)

Control Mode: Switching among Position control, Internal velocity command, and Position/Internal velocity command

Dimensions

Specifications and design of the products are subject to change without notice for the product improvement.

The dimension is for the A6SF Series, but outer dimension is the same as the A6SE and A6SG Series. Please refer to the catalog for detail dimension.

Connector Specification

Specifications and design of the products are subject to change without notice for the product improvement.

The dimension is for the A6SF Series, but outer dimension is the same as the A6SE and A6SG Series. Please refer to the catalog for detail dimension.
