ESTUN PRONET-E-20A 2kW High Power Output AC Servo Driver with 20A Rated Current and MODBUS/CANopen Communication

Large Image : ESTUN PRONET-E-20A 2kW High Power Output AC Servo Driver with 20A Rated Current and MODBUS/CANopen Communication

Product Details:

Place of Origin:	CHINA
Brand Name:	ESTUN
Model Number:	PRONET-E-20A

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	50pcs/month

Contact Now Chat Now

ESTUN PRONET-E-20A 2kW High Power Output AC Servo Driver with 20A Rated Current and MODBUS/CANopen Communication

Description

Condition:

Original Brand New

Warranty:

One Year

Shipping Way:

DHL FedEx

Application:

CNC Machine, Packaging Machine

Highlight:

2KW AC servo motor driver

ESTUN servo motor driver

PRONET-E-20A motor driver

ESTUN PRONET-E-20A Servo Drive System 2kW AC Servo Driver for Industrial Automation ProNet-E Series

Product Overview

The ESTUN PRONET-E-20A is a high-performance AC servo driver from the ProNet-E series, designed for precision motion control in industrial automation applications. With a rated output of 2kW and 200V AC power supply, this driver delivers exceptional positioning accuracy and reliable operation for applications including CNC machinery, industrial robotics, packaging equipment, and automated assembly lines.

As part of ESTUN's advanced ProNet-E platform, the PRONET-E-20A features position, speed, and torque control modes, supports MODBUS and CANopen communication protocols, and includes advanced control algorithms for superior dynamic response. The driver incorporates online auto-tuning, low-frequency vibration suppression, and electronic gearing functions for optimized motor control.

Model Number Breakdown

PRONET-E: ProNet-E series (enhanced version with CANopen)
20: 20A rated current (2kW power class)
A: 200V AC voltage class (single/three-phase)

Product Status: Active (In Production) - Available for new designs.

Key Features

2kW High Power Output
2.0 kW rated output with single/3-phase 200-240V AC power supply

20A Rated Current
20A current capacity for demanding medium-power applications

Multiple Control Modes
Switchable among Position, Speed, and Torque control

Dual Communication Protocols
MODBUS (RS-485) and CANopen support for flexible integration

Online Auto-Tuning
Real-time load inertia identification and automatic gain adjustment

Low Frequency Vibration Suppression
Reduces machine vibration at low frequencies

Electronic Gear Ratio
Flexible electronic gear setting for motor resolution matching

Built-in Panel Operator
7-segment LED display for parameter setting and monitoring

Technical Specifications

Specification	Value
Part Number	PRONET-E-20A
Brand	ESTUN Automation Technology Co., Ltd.
Series	ProNet-E Series
Product Status	Active (In Production)
Rated Output Power	2.0 kW (2000W)
Rated Current	20A
Input Voltage - Main Circuit	Single/3-phase 200-240V AC (+10%/-15%), 50/60Hz
Input Voltage - Control Circuit	Single-phase 200-240V AC (+10%/-15%), 50/60Hz
Control Modes	Position control, Speed control, Torque control
Communication Protocols	MODBUS (RS-485), CANopen
Speed Control Range	1:5000
Speed Regulation (Load)	0-100% load: ±0.01% max
Position Control Pulse Frequency	4Mpps max (line driver), 200kpps (open collector)
Number of I/O Inputs	8 channels (programmable)
Number of I/O Outputs	4 channels (programmable)
Regeneration	External regenerative resistor required (60W, 50Ω recommended)
Display	CHARGE (red), POWER (green), 7-segment LED display
Mounting Type	Base-mounted
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 85°C
Humidity	5% to 95% RH (non-condensing)
Vibration Resistance	4.9 m/s² max
Altitude	1000m or less
Protection Class	IP20

Control Modes

Control Mode	Description	Typical Applications
Position Control	Pulse train input for precise position command using clock + direction signals	CNC machinery, pick-and-place, positioning tables
Speed Control	Internal speed control, analog reference, or contact speed control with preset speeds	Conveyors, spindles, winding/unwinding
Torque Control	Analog torque command based on analog input voltage	Tension control, pressing, clamping

Additional Control Features

Contact Position Control: Sixteen preset position, speed, acceleration, deceleration, and stop time profiles for point-to-point motion
Internal Speed Control: Operation according to internal set speed with acceleration/deceleration profiles
Analog Reference Speed Control: Speed control based on analog input voltage

Communication Protocols

Protocol	Interface	Capability
MODBUS	RS-485	Standard industrial protocol for PLC/HMI integration, 1:n communication
CANopen	CAN bus	Real-time control, multi-axis synchronization, CiA 402 profile support

Compatible Motors

Motor Series	Rated Output Range	Encoder Types	Features
EMG Series	1.0kW - 5.0kW	131072 P/R absolute / resolver / 2500 P/R incremental	High-performance, compact design
EMJ Series	0.2kW - 2.0kW	2500 P/R incremental	Cost-effective, reliable

Motor Compatibility Notes:

For absolute encoder operation: Use motors with 131072 P/R absolute encoder
For resolver applications: For harsh environments requiring high reliability
For incremental operation: Use 2500 P/R incremental encoder (wire-saving type available)

Installation & Setup

Mechanical Installation

Mounting Type: Base-mounted design for control panel installation
Mounting Orientation: Install perpendicular to the wall (vertical orientation) for proper cooling
Mounting Surface: Flat, rigid surface with adequate heat dissipation
Clearance Requirements:
- Horizontal spacing: 10mm minimum between drives
- Vertical spacing: 50mm minimum above and below
Cooling: Natural convection - ensure adequate ventilation
Environment: Free from condensation, vibration, and shock

Environmental Requirements

Operating Temperature: 0°C to 55°C
Storage Temperature: -20°C to 85°C
Humidity: 5% to 95% RH (non-condensing)
Vibration: 4.9 m/s² or less
Altitude: 1000m or less for full specifications

Electrical Connection

Main Circuit Power: Single or 3-phase 200-240V AC - verify phase configuration before connection
Control Circuit Power: Single-phase 200-240V AC - separate from main circuit
Motor Connection: Connect to compatible ESTUN servomotor (U, V, W terminals)
Encoder Connection: Connect to CN2 connector for feedback
Communication Wiring: RS-485 (MODBUS) or CAN bus as required
Grounding: Single-point grounding required (grounding resistance 100Ω or below)

Noise Reduction Guidelines:

Separate high-voltage cables from low-voltage cables by at least 300mm
Use cables as short as possible
Single point grounding for servomotor and servo drive
Never use a line filter for the power supply circuit

Regeneration Notes:

External Regenerative Resistor Required: 60W, 50Ω resistor recommended for ProNet-E-20A
Parameter Setting: Change Pn521.0 from "1" to "0" when using external regenerative resistor
Application Note: Required for applications with frequent acceleration/deceleration or vertical axes

Configuration

Panel Operator: Built-in 7-segment LED display and keys for local parameter adjustment
Software: ESView communication software for PC-based parameter management and real-time monitoring
Control Mode Selection: Set via parameter (Pn005.1)
Electronic Gear Setting: Program electronic gear ratio for position control
Auto-Tuning: Enable online auto-tuning for optimal gain settings
Test Operation: Perform JOG operation before full system integration

Safety Precautions

Qualified Personnel Only: All installation, wiring, operation, and maintenance must be performed by qualified personnel only
Residual Voltage Warning: Residual voltage remains even after power is turned off. Always wait at least 5 minutes after CHARGE indicator turns off before inspection
No Hot Plugging: Do not plug or unplug connectors while power is on
Direct Motor Connection: Do not connect the servomotor directly to the local electrical network - this will damage the motor
Voltage Resistance Test: If conducting testing, use AC 1500Vrms, 1 minute, 100mA between L1, L2 terminals and frame ground

Documentation Resources

Document	Description
ProNet Series AC Servo User's Manual (V2.04/V2.10)	Complete installation, wiring, and operation guide
ESView Software	PC-based configuration and monitoring software
ProNet-E Series Specifications	Detailed technical specifications

Applications

The ESTUN PRONET-E-20A servo driver is ideal for:

CNC Machinery
Milling machines, routers, engraving equipment, and lathes

Industrial Robotics
Articulated arms, SCARA robots, and collaborative robots

Packaging Machinery
Wrapping, filling, sealing, and labeling equipment

Automated Assembly Lines
Pick-and-place equipment and positioning systems

Electronic Manufacturing
PCB assembly, pick-and-place, and inspection equipment

Textile Machines
High-speed winding and processing equipment

Printing & Converting
Web handling and tension control applications

Woodworking Machinery
CNC routers and carving machines

Food Processing Machinery
Conveyor synchronization and filling equipment

Laboratory Automation
Precision positioning and sample handling
