Eaton MTL7741 Dual Channel 4-20mA Zener Barrier with DIN Rail Mounting for Hazardous Areas

Large Image : Eaton MTL7741 Dual Channel 4-20mA Zener Barrier with DIN Rail Mounting for Hazardous Areas

Product Details:

Place of Origin:	India
Brand Name:	MTL
Certification:	CE
Model Number:	MTL7741

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Eaton MTL7741 Dual Channel 4-20mA Zener Barrier with DIN Rail Mounting for Hazardous Areas

Description

Condition:

Original Brand New

Warranty:

One Year

Shipping Way:

DHL FedEx

Application:

Oil Gas Chemical Industry

Highlight:

MTL Zener Barrier DIN-rail mounting

Intrinsic Safety Barrier MTL7700 Series

MTL7741 safety barriers with warranty

Eaton MTL MTL7741 Dual Channel 4-20mA Current Loop Zener Intrinsic Safety Barrier Ex ia ATEX DIN Rail Hazardous Area

Product Overview

The MTL7741 is a single-channel Zener barrier from Eaton's Crouse-Hinds series MTL7700 range, specifically designed to interface switch or proximity detector inputs with a changeover relay output in hazardous area installations.

This intrinsically safe passive device safely transfers electrical signals between safe and hazardous areas while limiting voltage and current to prevent ignition of flammable atmospheres. With a 24V DC supply and 26mA switching current, the MTL7741 is the ideal solution for digital input applications requiring relay output isolation in Zone 0, 1, and 2 hazardous locations (gas groups IIC, IIB, IIA).

Key Features & Benefits

Built-in Overvoltage Protection: Integrated overvoltage protection safeguards the circuit from voltage spikes and transients
Single-Channel with Relay Output: One intrinsically safe channel with a changeover relay output (C/O relay) – provides isolated switching for digital input applications
24V DC Operation: Rated supply voltage of 22.9-30 V DC (nominal 24V DC) – compatible with standard industrial control systems
26mA Switching Current: Adequate current handling for proximity sensors and switch inputs
Proximity Sensor or Switch Input: Specifically designed for interfacing with proximity detectors (NAMUR) and mechanical switch inputs
Removable Terminals: Unique removable terminal blocks for easy cabling, maintenance, and loop disconnect by simply unplugging terminals from the side of the module
Bussed Power Capability: Integrated bussed power feed facility reduces cabling requirements when used with the MTL7798 power feed module
Angled Wire Entry: Wire entry is angled to assist wiring within limited space enclosures
Ultra-Slim DIN Rail Mounting: Compact 12.6 mm width for standard 35 mm T-section DIN rail
Dual-Stage Protection: Contains two stages of pulse-tested Zener diodes and an 'infallible' terminating resistor
Direct Replacement for MTL700 Series: Compatible terminal numbering and safety descriptions allow direct replacement of older MTL700 series barriers
Global Approvals: ATEX, IECEx, UL, CSA certifications for international installation flexibility

Technical Specifications

Parameter	Value
Manufacturer	Eaton (Crouse-Hinds series MTL)
Series	MTL7700 Range
Product Model	MTL7741
Product Type	Zener Barrier (Intrinsic Safety Barrier)
Number of Channels	1 (single-channel)
Input Type	Proximity sensor (NAMUR) or switch input
Output Type	Changeover relay (C/O relay)

Electrical Ratings

Parameter	Value
Rated Supply Voltage DC	22.9 - 30 V DC (nominal 24V DC)
Supply Voltage Range	22 - 35 V DC
Switching Current	26 mA
Maximum Safety Current	19 mA
Maximum Safety Voltage	35 V DC
Safety Current Resistance	300 Ω

Mechanical Specifications

Parameter	Value
Width	12.6 mm
Height	90 mm
Depth/Length	105 mm
Weight	140 g
Enclosure Material	Polycarbonate
Mounting	35 mm T-section DIN rail (EN 60715)
Terminals	Removable screw terminals, colour-coded

Certifications & Approvals

Certification	Status	Region
ATEX	✅ Certified	Europe
IECEx	✅ Certified	International
UL	✅ Certified	USA
CSA	✅ Certified	Canada
TIIS (Japan)	⚠️ Expired (2024-11-03)	Japan
CCC Ex (China)	Available upon request	China
RoHS	✅ Compliant	--

Applications

The MTL7741 is specifically designed for digital input and relay output applications in hazardous area installations:

Industry	Application
Oil & Gas	Proximity sensor monitoring for valve position feedback on offshore platforms
Chemical Processing	Switch input isolation for emergency shutdown systems in explosive atmospheres
Pharmaceutical	Digital input protection for batch processing equipment requiring Ex certification
Factory Automation	Proximity detector interfacing for conveyor systems in hazardous locations
Power Generation	Turbine monitoring systems with switch input and relay output isolation
Marine & Offshore	Marine control systems requiring intrinsic safety certification

MTL7741 vs. Related MTL7700 Series Models

Model	Channels	Input Type	Output Type	Supply Voltage	Switching Current	Primary Application
MTL7741	1	Proximity/Switch	Relay (C/O)	24V DC	26 mA	Relay output switching
MTL7706+	1	General purpose	Passive transistor	24V DC	93 mA	General purpose digital input
MTL7787+	2	General purpose	Passive transistor	24V DC	93 mA	Dual-channel digital input
MTL7765AC	2	AC/DC sensor	Passive	15V	150 mA	AC/DC sensor input
MTL7707+	1	Proximity	Solid-state	24V DC	--	Proximity detector input

Ordering Information

Item	Details
Part Number	MTL7741
Brand	Eaton (Crouse-Hinds series MTL)
Product Family	MTL7700 Range – Zener Barriers
Tariff Code	85364900
EAN	3066227675736
Weight	0.140 kg
Country of Origin	India
Condition	New, Original, Factory Sealed
