MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver

MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver
MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver

Large Image :  MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver

Product Details:
Place of Origin: England
Brand Name: MTL
Model Number: MTL5522
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: original package
Delivery Time: 3 working days
Payment Terms: T/T,Western Union
Supply Ability: 500pcs/month
Contact Now Chat Now

MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver

Description
Condition: Original Brand New Warranty: One Year
Shipping Way: DHL FedEx Express Application: Automation Industries, Oil, Gas, Chemical Industries
Certificate: CE ISO TUV
Highlight:

MTL safety barrier isolator

,

intrinsic safety solenoid driver

,

MTL5522 alarm driver

MTL5522 MTL Safety Barriers Isolators Solenoid Alarm Driver
Eaton Crouse-Hinds series MTL5500 solenoid/alarm driver featuring 1 channel digital output, 20-35 Vdc power supply, and comprehensive safety certifications for hazardous locations.
Product Name Eaton Crouse-Hinds series MTL5500 solenoid/alarm driver
Catalog Number MTL5522 - FSM ASSESSED
EAN 3066227675830
Product Dimensions 109.8 mm (L) × 118.8 mm (H) × 15.8 mm (W)
Product Weight 150 g
Global Catalog MTL5522
Product Type Solenoid/alarm driver
Technical Specifications
Type Loop-powered, IIB
Area Classification Hazardous/Classified Locations
Standards IEC, IECEx/ATEX
Hazardous Rating Zone 0
Operating Temperature -20°C to 60°C
Storage Temperature -40°C to 80°C
Humidity 5-95% relative humidity
Signal Type Digital output
Response Time Output within 10% of final value within 100ms
Number of Channels 1
Terminal Capacity Accepts conductors up to 2.5mm² stranded or single-core
Mounting Method T-section 35mm DIN rail
EMC EN61326
Ripple <0.5% of maximum output, peak-to-peak
Safety Integrity Level SIL1 and SIL3 according to IEC61508
Electrical Connection Crimp ferrules
Electrical Characteristics
Power Supply 20-35 Vdc
Current Consumption 125mA at 24V
Current Limit 70mA minimum
Maximum Input Voltage 20-35 Vdc
Minimum Output Voltage 10.7V at 70mA
Maximum Output Voltage 24V from 158Ω
Galvanic Isolation 250V rms between safe-area circuits and power supply
Power Dissipation 1.4W at 24V
Indication Features
  • LED status indication
  • Yellow LED color for status monitoring
