MTL5532 MTL Safety Barrier Eaton Crouse-Hinds series MTL5500 Pulse Isolator

Large Image : MTL5532 MTL Safety Barrier Eaton Crouse-Hinds series MTL5500 Pulse Isolator

Product Details:

Place of Origin:	England
Brand Name:	MTL
Model Number:	MTL5532

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MTL5532 MTL Safety Barrier Eaton Crouse-Hinds series MTL5500 Pulse Isolator

Description

Products Name:	Safety Barrier	Condition:	Original Brand New
Warranty:	One Year	Shipping Way:	DHL FedEx Express
Application:	Automation Industries, Oil, Gas, Chemical Industries	Certificate:	CE ISO TUV
Highlight:	MTL5500 series safety barrier , Eaton Crouse-Hinds pulse isolator , MTL5532 intrinsic safety barrier

MTL5532 MTL Safety Barrier Eaton Crouse-Hinds Series MTL5500 Pulse Isolator

The Eaton Crouse-Hinds series MTL5500 pulse isolator is a single-channel safety barrier designed for hazardous locations. This industrial-grade device provides reliable signal isolation with advanced monitoring capabilities.

Key Features:

24mA operating current with 20-35 Vdc power supply
1.35W maximum power dissipation at 24V
Multi-color LED status indication (Green = power, Yellow = status, Red = LFD)
Output ON when input >2.1mA, Output OFF when input <1.2mA
Designed for hazardous/classified locations with Zone 0 certification

Product Specifications

Basic Information

Product Name	Eaton Crouse-Hinds series MTL5500 pulse isolator
Catalog Number	MTL5532
Product Type	Pulse isolator
Dimensions	109.8mm (L) × 118.8mm (H) × 15.8mm (W)
Weight	150g

Technical Specifications

Type	Pulse and 4/20mA current outputs
Area Classification	Hazardous/Classified Locations
Standards	IEC, IECEx/ATEX
Hazardous Rating	Zone 0
Operating Temperature	-20°C to 60°C
Storage Temperature	-40°C to 80°C
Humidity	5-95% relative humidity
Signal Type	Pulse and vibration
Input Impedance	>10kΩ
Response Time	60ms
Load Resistance	0-450Ω at 20mA
Output Signal Range	4-20mA
Number of Channels	1, fully floating
Terminal Capacity	Accepts conductors up to 2.5mm² stranded or single-core
Mounting Method	T-section 35mm DIN rail
EMC	EN61326
Hysteresis	0.2mA (650Ω)
Ripple	<50µA peak-to-peak
Configuration	Personal computer running MTL PCS45 software with PCL45USB serial interface
Electrical Connection	Crimp ferrules
Galvanic Isolation	250V rms between safe-area circuits and power supply
Switching Frequency	0-10 kHz (analogue output), 0-50 kHz (pulse output mode)
Transfer Accuracy	Better than 20µA
Temperature Drift	<1.0µA/°C
Under/Over Range	0-22mA

Power & LED Specifications

Current	24 mA
Power Supply	20-35 Vdc
Power Dissipation	1.75W maximum at 35V, 1.35W maximum at 24V
LED Power Indicator	Green
LED Status Indicator	Yellow
LED LFD Indicator	Red
