MTL5541S MTL Intrinsically Safe Barriers MTL5500 Repeater Power Supply

Large Image : MTL5541S MTL Intrinsically Safe Barriers MTL5500 Repeater Power Supply

Product Details:

Place of Origin:	England
Brand Name:	MTL
Model Number:	MTL5541S

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MTL5541S MTL Intrinsically Safe Barriers MTL5500 Repeater Power Supply

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	MTL Intrinsically Safe Barriers , MTL Safety Barrier , MTL5541S

Eaton Crouse-Hinds series MTL5500 repeater power supply, 1 channel, Analogue input, 24 Vdc max., 20-35 Vdc, 1.0W at 24 Vdc dissipation, 51mA at 24V, 4-20mA signal, HART (terminals 1 & 2 only), LED: Green = power, 2- or 3-wire transmitters

Product Name	Eaton Crouse-Hinds series MTL5500 repeater power supply
Catalog Number	MTL5541S - FSM ASSESSED
EAN	3066227675819
Product Length/Depth	109.8 mm
Product Height	118.8 mm
Product Width	15.8 mm
Product Weight	150 g
Global Catalog	MTL5541S
Product Type	Repeater power supply

Type	2- or 3-wire transmitters
Area classification	Hazardous/Classified Locations
Standards type	IEC IECEx/ATEX
IECEx/ATEX hazardous rating	Zone 0
Minimum Ambient Operating Temperature	-20 °C
Maximum Ambient Operating Temperature	60 °C
Minimum Ambient Storage Temperature	-40 °C
Maximum Ambient Storage Temperature	80 °C
Humidity	5-95% relative humidity
Signal Type	Analogue input
Signal Range	4-20mA
Response Time	Settles to within 10% of final value within 50µs
Number of Channels	1
Terminal Capacity	Accepts conductors of up to 2.5mm2 stranded or single-core
Mounting Method	T-section 35mm DIN rail
EMC	EN61326
Ripple	<50µA peak-to-peak
Safety Integrity Level According to IEC61508	SIL2 and SIL3
Communication Supported	HART (terminals 1 & 2 only)
Electrical Connection	Crimp ferrules
Power Supply	20-35 Vdc
Current Consumption	51mA at 24V
Maximum Safe Voltage	24 Vdc
Galvanic Isolation	250V rms between safe-area circuits and power supply
LED Indication	Yes
LED Color - Power	Green
Power Dissipation	1.0W at 24 Vdc
Transfer Accuracy	Better than 15µA
Temperature Drift	<0.8µA/°C
