PEPPERL+FUCHS Safety Barrier Voltage Repeater KFD2-VR2-Ex1.50M

Large Image : PEPPERL+FUCHS Safety Barrier Voltage Repeater KFD2-VR2-Ex1.50M

Product Details:

Place of Origin:	Singapore
Brand Name:	PEPPERL+FUCHS
Model Number:	KFD2-VR2-Ex1.50M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

PEPPERL+FUCHS Safety Barrier Voltage Repeater KFD2-VR2-Ex1.50M

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	PEPPERL+FUCHS safety barrier voltage repeater , intrinsic safety barrier with warranty , KFD2-VR2-Ex1.50M voltage repeater

PEPPERL+FUCHS Safety Barrier Voltage Repeater KFD2-VR2-Ex1.50M

Product Overview

The PEPPERL+FUCHS KFD2-VR2-Ex1.50M is a 1-channel isolated barrier designed for intrinsic safety applications in industrial environments.

Technical Specifications

Type	1-channel isolated barrier
Power Supply	24 V DC (Power Rail)
Input Voltage	0 mV ... ± 50 mV
Output Voltage	0 mV ... ± 50 mV
Sensor Breakage Detection	Selectable up/downscale

Functional Description

This isolated barrier transfers low voltage signals from various sensors located in hazardous areas to safe areas, including:

Load cells
Strain gauges
Operational amplifiers
Inductive oscillation sensors

The input voltage from terminals 4 and 5 is precisely transferred to terminals 7 and 8. The input, output, and power supply circuits are galvanically isolated from each other for maximum safety.

Upscale or downscale lead breakage monitoring can be selected via switches located on the front panel of the device.

Important Note: This unit requires three minutes after power-up to reach the accuracy cited in the technical data.
