PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex1.51P

Large Image : PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex1.51P

Product Details:

Place of Origin:	Singapore
Brand Name:	PEPPERL+FUCHS
Model Number:	KFD0-CS-Ex1.51P

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex1.51P

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	PEPPERL+FUCHS safety barrier repeater , intrinsic safety barrier current driver , KFD0-CS-Ex1.51P safety repeater

PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex1.51P

The PEPPERL+FUCHS KFD0-CS-Ex1.51P is a 1-channel isolated barrier designed for intrinsic safety applications in industrial environments. This loop-powered device provides reliable signal transmission between hazardous and non-hazardous areas.

Key Specifications

1-channel isolated barrier for intrinsic safety applications
24 V DC loop-powered supply
Current input/output range: 0 mA to 40 mA
I/P or transmitter power supply capability
High accuracy: 1%
Reverse polarity protection
Safety certification: Up to SIL 2 (SC 3) according to IEC/EN 61508

Primary Function

This isolated barrier safely transfers DC signals from fire alarms and smoke detectors in hazardous areas to non-hazardous control systems. The device also supports control of I/P converters, valves, indicators, and audible alarms. Built-in reverse polarity protection prevents damage from wiring errors.

Application Scenarios

Circuit Isolation for Control Systems: The device provides isolation for controlling positioners, I/P converters, and similar equipment. A current source is connected to terminals in the non-explosion-hazardous area.

Current Signal Isolation: Used for isolating current signals from fire detectors and similar sensors. When a voltage source is connected to terminals in the non-hazardous area, specific measurement currents across passive sensors can be measured using a series resistor (minimum 50 Ω).

Installation Note: The device is loop-powered, eliminating the need for additional power supply connections on the control side. Always verify proper voltage availability for field devices using the technical specifications.
