Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD

Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD
Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD

Large Image :  Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD

Product Details:
Place of Origin: Japan
Brand Name: Proface
Model Number: PFXET6600WAD
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: original package
Delivery Time: 3 working days
Payment Terms: T/T,Western Union
Supply Ability: 500pcs/month
Contact Now Chat Now

Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD

Description
Condition: Original Brand New Warranty: One Year
Shipping Way: DHL FedEx Express Application: Automation Industries, Oil, Gas, Chemical Industries
Certificate: CE ISO TUV
Highlight:

Proface 12 Inch HMI

,

HMI Touch Panel PFXET6600WAD

Proface 12 Inch HMI Touch Panel Screen PFXET6600WAD


Main
Product or component type Touch panel screen
Range of product Pro-face ET6000
Software package GP-Pro EX
Processor name ARM Cortex-A8


Complementary
Display size 12 inch
Display type Colour TFT LCD
Display colour 16 million colours
Display resolution 1280 x 800 pixels WXGA
Touch panel Single touch analogue resistive
Brightness 16 levels
Character font Greek

Latin
[Us] rated supply voltage 24 V DC +/- 20 %
Inrush current 30 A
Local signalling Status LED green, steady for offline
Status LED green, steady for operating
Status LED green, flashing for logic stop
Status LED orange, flashing for software starting up
Status LED red, steady for power supply (ON)
Status LED, off for power supply (OFF)
Power consumption in W 14 W
Port Ethernet 10/100BASE
Memory description Device memory 256 MB
User data memory 64 MB
Backup memory 128 kB
Integrated connection type 1 COM1 serial link - 1 SUB-D 9-pin male - RS232C (rate: 2400...115200 bps)bottom
1 COM2 serial link - 1 SUB-D 9-pin male - RS422/RS485 (rate: 2400...115200 bps)bottom
COM2 serial link (rate: 2400...187500 bps)bottom
1 Ethernetbottom
1 USB 2.0 type Aback
1 USB 2.0 type micro Bback
Supply External supply
Realtime clock Built-in 0...50 °C
Built-in 10...90 % RH
Fixing mode By 6 screws, mounting on 1.6...5 mm thick panel
Cut-out dimensions 295 x217 mm panel cut dimension
Width 311 mm
Height 233 mm
Depth 50 mm
Net weight 1.62 kg


Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 12.500 cm
Package 1 Width 30.500 cm
Package 1 Length 40.000 cm
Package 1 Weight 2.252 kg
Unit Type of Package 2 S06
Number of Units in Package 2 8
Package 2 Height 75.000 cm
