Proface 15 Inch HMI Touch Panel Screen PFXET6700WAD

Large Image : Proface 15 Inch HMI Touch Panel Screen PFXET6700WAD

Product Details:

Place of Origin:	Japan
Brand Name:	Proface
Model Number:	PFXET6700WAD

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Proface 15 Inch HMI Touch Panel Screen PFXET6700WAD

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Proface 15 Inch HMI , 15 Inch HMI PFXET6700WAD

Main

Product or component type

Touch panel screen

Range of product

Pro-face ET6000

Software package

GP-Pro EX

Processor name

ARM Cortex-A8

Complementary

Display size

15 inch

Display type

Colour TFT LCD

Display colour

16 million colours

Display resolution

1366 x 768 pixels FWXGA

Touch panel

Single touch analogue resistive

Brightness

16 levels

Character font

Greek
Latin

[Us] rated supply voltage

24 V DC +/- 20 %

Inrush current

30 A

Local signalling

Status LED green, steady for offline
Status LED green, steady for operating
Status LED green, flashing for logic stop
Status LED orange, flashing for software starting up
Status LED red, steady for power supply (ON)
Status LED, off for power supply (OFF)

Power consumption in W

18.5 W

Port Ethernet

10/100BASE

Memory description

Device memory 256 MB
User data memory 64 MB
Backup memory 128 kB

Integrated connection type

1 COM1 serial link - 1 SUB-D 9-pin male - RS232C (rate: 2400...115200 bps)bottom
1 COM2 serial link - 1 SUB-D 9-pin male - RS422/RS485 (rate: 2400...115200 bps)bottom
COM2 serial link (rate: 2400...187500 bps)bottom
1 Ethernetbottom
1 USB 2.0 type Aback
1 USB 2.0 type micro Bback

Supply

External supply

Realtime clock

Built-in 0...50 °C
Built-in 10...90 % RH

Fixing mode

By 6 screws, mounting on 1.6...5 mm thick panel

Cut-out dimensions

394 x 250 mm panel cut dimension

Width

412 mm

Height

268 mm

Depth

50 mm

Net weight

2.52 kg

Environment

Immunity to microbreaks

5 ms

Enclosure material

Front material

Plastic

Product certifications

CE
UL
KC
UKCA

NEMA degree of protection

NEMA 4 front panel (indoor use)
NEMA 13 front panel (in enclosure)

Standards

IEC 61000-6-4
IEC 61000-6-2
IEC 61131-2
UL 61010-2-201
CSA C22.2 No 61010-1-201

Directives

2014/35/EU - low voltage directive
2014/30/EU - electromagnetic compatibility

IP degree of protection

IP20 (rear panel) conforming to IEC 61131-2
IP65 (front panel) conforming to IEC 61131-2

Ambient air temperature for operation

0…50 °C

Ambient air temperature for storage

-20…60 °C

Relative humidity

10…90 % non-condensing

Operating altitude

2000 m

Vibration resistance

+/- 3.5 mm (f = 5…9 Hz) X, Y, Z directions for 10 cycles (approx. 100 min) conforming to IEC 61131-2
9.8 m/s² (f = 9…150 Hz)

Shock resistance

147 m/s² for 11 ms (X, Y, Z directions for 3 times) conforming to IEC 61131-2

Electromagnetic compatibility

Electrical fast transient/burst immunity test - test level: 2 kV (power ports) conforming to IEC 61000-4-4
Electrical fast transient/burst immunity test - test level: 1 kV (signal ports)
Electrostatic discharge immunity test - test level: 6 kV (contact discharge) conforming to IEC 61000-4-2 level 3
Electrostatic discharge immunity test - test level: 8 kV (air discharge)

Packing Units

Unit Type of Package 1

PCE

Number of Units in Package 1

Package 1 Height

12.500 cm

Package 1 Width

36.000 cm

Package 1 Length

52.500 cm

Package 1 Weight

3.390 kg

Unit Type of Package 2

S06

Number of Units in Package 2

Package 2 Height

75.000 cm

Package 2 Width

60.000 cm

Package 2 Length

80.000 cm

Package 2 Weight

36.890 kg
