Model

PZ-V71

Type

Intelligent reflective

Output

NPN

Detecting distance

20 to 900 mm
0.79" x 35.43"
(300 x 300 mm
11.81" x 11.81"
white mat paper)*1

Setting distance

150 to 900 mm5.91" x 35.43" (300 x 300 mm11.81" x 11.81"white mat paper)

Light source.

Infrared LED

Sensitivity adjustment

Automatic push button

Response time

1 ms max.

Operation mode

LIGHT-ON/DARK-ON (switch-selectable)

Indicator lamp

Output: orange LED, stable operation: green LED

Control output

100 mA (24 V) max., Residual voltage: 1 V max.

Digital monitor

7-segment, 3-digit red LED

Protection circuit

Reversed polarity, overcurrent protection, surge absorber

Rating

Power voltage

12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less

Power consumption

45 mA max.

Environmental resistance

Enclosure rating

IP67

Ambient light

Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max.

Ambient temperature

-20 to +55 °C -4 to 131 °F (No freezing)

Relative humidity

35 to 85 % RH (No condensation)

Vibration resistance

10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions

Shock resistance

1,000 m/s2, 6 times in each of the X, Y, and Z directions

Case material

Glass-fiber reinforced plastic

Accessories

―

Weight

Approx. 70 g (including 2-m 6.6' cable)
