PEPPERL+FUCHS Isolated Barrier Universal Temperature Converter KCD2-UT2-Ex1

Large Image : PEPPERL+FUCHS Isolated Barrier Universal Temperature Converter KCD2-UT2-Ex1

Product Details:

Place of Origin:	Singapore
Brand Name:	PEPPERL+FUCHS
Model Number:	KCD2-UT2-Ex1

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

PEPPERL+FUCHS Isolated Barrier Universal Temperature Converter KCD2-UT2-Ex1

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	PEPPERL+FUCHS temperature converter , isolated barrier KCD2-UT2-Ex1 , intrinsic safety barrier with warranty

PEPPERL+FUCHS Isolated Barrier Universal Temperature Converter KCD2-UT2-Ex1

The Pepperl+Fuchs KCD2-UT2-Ex1 Universal Temperature Converter is a 1-channel isolated barrier designed for intrinsic safety applications in industrial environments.

Key Features

1-channel isolated barrier for hazardous area applications
24 V DC supply via Power Rail
Accepts thermocouple, RTD, potentiometer, or voltage input signals
Current output: 0/4 mA to 20 mA
Sink or source mode operation
Configurable using PACTware software
Line fault (LFD) and sensor burnout detection
SIL 2 certification according to IEC/EN 61508 / IEC/EN 61511

Function & Application

This isolated barrier converts RTD input signals or thermocouple input signals from hazardous areas to 0/4 mA to 20 mA signals in safe areas. The removable terminal block KC-CJC-** is available for thermocouples when internal cold junction compensation is required.

Fault conditions are indicated by an LED and user-configured fault indication outputs. When operated via Power Rail, an additional collective error message is available for comprehensive system monitoring.

Configuration

The device is easily configured using PACTware configuration software, providing flexible setup options for various industrial applications.
