MTL4531 MTL Safety Barriers Eaton Crouse-Hinds series MTL4500 Vibration Transducer Interface

Large Image : MTL4531 MTL Safety Barriers Eaton Crouse-Hinds series MTL4500 Vibration Transducer Interface

Product Details:

Place of Origin:	England
Brand Name:	Eaton
Model Number:	MTL4531

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	200pcs/month

Contact Now Chat Now

MTL4531 MTL Safety Barriers Eaton Crouse-Hinds series MTL4500 Vibration Transducer Interface

Description

Condition:

Original Brand New

Warranty:

One Year

Shipping Way:

DHL FedEx

Application:

Oil Gas Chemical Industry

Highlight:

MTL4531 safety barrier

Eaton Crouse-Hinds MTL4500

vibration transducer interface

The MTLx531 repeats a signal from a vibration sensor in a hazardous area, providing an output for a monitoring system in the safe area. The interface is compatible with 3-wire eddy-current probes and accelerometers or 2-wire current sensors; the selection is made by a switch on the side of the module.

Product Name	Eaton Crouse-Hinds series MTL4500 vibration transducer interface
Catalog Number	MTL4531
Product Length/Depth	104.8 mm
Product Height	121.8 mm
Product Width	15.8 mm
Product Weight	140 g
Product Type	Vibration transducer interface

Certifications and compliances

Area classification	Hazardous/Classified Locations
Standards type	IEC IECEx/ATEX
IECEx/ATEX hazardous rating	Zone 0
EMC	EN61326
Safety Integrity Level According to IEC61508	SIL2

Product specifications

Signal Type	Pulse and vibration
Number of Channels	1
Mounting Method	MTL4500 range of backplanes
Power Dissipation	1.33W
Signal Range	Minimum: -20V, maximum: -0.5V
Transfer Accuracy	<±50mV (DC)
Switching Frequency	-3 dB at 47 kHz (typical)
Galvanic Isolation	50V between safe-area circuits and power supply
Type	2- or 3-wire
