MTL7706+ Zener Barrier Intrinsic Safety Barrier 20-35 Vdc 4-20mA DIN Rail Mount

Large Image : MTL7706+ Zener Barrier Intrinsic Safety Barrier 20-35 Vdc 4-20mA DIN Rail Mount

Product Details:

Place of Origin:	India
Brand Name:	MTL
Model Number:	MTL7706+

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MTL7706+ Zener Barrier Intrinsic Safety Barrier 20-35 Vdc 4-20mA DIN Rail Mount

Description

Condition:

MTL Original Brand New

Warranty:

One Year

Application:

Oil Gas Chemical Industry

Shipping Way:

DHL FedEx

Highlight:

20-35 Vdc Zener Barrier

4-20mA Intrinsic Safety Barrier

DIN rail mount MTL7706+

MTL Zener Barrier MTL7706+

Eaton Crouse-Hinds series MTL7700 Zener barrier designed for 'smart' 2-wire 4/20mA transmitters. Features 20-35 Vdc power supply, 4-20mA switching current, and built-in overvoltage protection in a durable polycarbonate housing with DIN rail mounting.

Product Specifications

Product Name	Eaton Crouse-Hinds series MTL7700 Zener barrier
Catalog Number	MTL7706+
EAN	3066227675752
Product Type	Zener barrier

Technical Details

Number of Channels	1
Rated Supply Voltage	20-35 Vdc
Power Supply Type	DC
Switching Current	4-20mA
Load Resistance	0-500Ω
Type	2-wire
Application	For 'smart' 2-wire 4/20mA transmitters

Physical Specifications

Length/Depth	105 mm
Height	90 mm
Width	12.6 mm
Weight	140 g
Material	Polycarbonate
Mounting Method	DIN rail

Environmental Specifications

Minimum Operating Temperature	-20 °C
Maximum Operating Temperature	60 °C

Key Features

Built-in overvoltage protection
Single channel design for precise control
Compact DIN rail mounting for easy installation
Durable polycarbonate construction
Compatible with smart 2-wire 4/20mA transmitters
