Estun Servo Motor 750W AC Servo Motor with 200V-220V and 3000RPM for Industrial Automation

Large Image : Estun Servo Motor 750W AC Servo Motor with 200V-220V and 3000RPM for Industrial Automation

Product Details:

Place of Origin:	CHINA
Brand Name:	ESTUN
Model Number:	EMJ-08APB22

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	20pcs/month

Contact Now Chat Now

Estun Servo Motor 750W AC Servo Motor with 200V-220V and 3000RPM for Industrial Automation

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	750W AC servo motor , ESTUN AC servo motor , industrial AC servo motor

EMJ-08APB22 Estun Servo Motor - 750W, 200V-220V, 3000RPM with 24V Brake

Product Overview

The Estun EMJ-08APB22 is a 750W (0.75kW) high-performance AC Servo Motor specifically engineered for applications requiring safety and precision. As a standout model in the EMJ Series, it features a built-in electromagnetic brake, making it the definitive solution for vertical Z-axis control, elevators, and safety-critical mechanical arms.

With a rated speed of 3,000 RPM and a medium-inertia design, the EMJ-08APB22 provides the perfect balance between rapid dynamic response and exceptional load stability. Its high-resolution 20-bit encoder ensures sub-micron positioning accuracy for the most demanding automated environments.

Technical Specifications

Feature	Specification
Model Number	EMJ-08APB22
Rated Output	750 W (0.75 kW)
Brake Configuration	Integrated 24V DC Electromagnetic Brake
Voltage	200 V - 230 V AC
Rated Torque	2.39 Nm (Peak Torque: 7.16 Nm)
Rated Speed	3000 r/min (Max: 5000 r/min)
Encoder	20-bit Incremental / 17-bit Absolute
Inertia Type	Medium Inertia (Superior Stability)
Protection Rating	IP65 (Dust-proof and splash-resistant)
Shaft Detail	Standard Keyway with Oil Seal

Key Benefits

1. Integrated Fail-Safe Brake

The built-in 24V brake automatically engages when power is lost or the drive is disabled. This prevents the mechanical load from falling or sliding, protecting expensive tooling and ensuring operator safety in vertical motion applications.

2. Optimized Medium Inertia

The EMJ series is designed with medium inertia to provide better control over load ratios. This significantly reduces mechanical "hunting" and vibration, allowing for smoother motion and shorter settling times compared to low-inertia motors.

3. High-Precision 20-bit Feedback

Equipped with a high-resolution serial encoder, the EMJ-08APB22 provides over 1 million pulses per revolution. This resolution delivers ultra-smooth rotation at low speeds and precise positioning for high-accuracy CNC and pick-and-place tasks.

4. Rugged Industrial Build (IP65)

Designed for the factory floor, the IP65 rating and factory-installed oil seal ensure the motor remains operational even in environments with dust, humidity, or oil mist.

Primary Industrial Applications

CNC Machine Z-Axes: Prevents spindle drop during power-off
Automated Pick-and-Place: High-speed vertical component handling
Robotic Arms: Joint control for multi-axis industrial robots
Packaging & Labeling: Synchronized motion with safety-stop requirements
Medical Lab Automation: Precise, fail-safe sample positioning

Buy with Confidence

Condition: 100% Brand New & Original Estun (Factory Sealed)
Global Logistics: Fast shipping via DHL, FedEx, and UPS. Safe, reinforced packaging
Technical Support: Expert help pairing with ProNet-E-08A or EDB-08AMA drives
Authenticity: Guaranteed genuine parts with full traceability
