PEPPERL+FUCHS Safety Barrier KFD2-CR4-1.2O

Large Image : PEPPERL+FUCHS Safety Barrier KFD2-CR4-1.2O

Product Details:

Place of Origin:	Singapore
Brand Name:	PEPPERL+FUCHS
Model Number:	KFD2-CR4-1.2O

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original brand new
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

PEPPERL+FUCHS Safety Barrier KFD2-CR4-1.2O

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	PEPPERL+FUCHS intrinsic safety barrier , KFD2-CR4-1.2O safety barrier , industrial safety barrier with warranty

PEPPERL+FUCHS Safety Barrier KFD2-CR4-1.2O

Product Overview

The KFD2-CR4-1.2O is a high-performance 1-channel signal conditioner and safety barrier designed for industrial applications requiring signal isolation and distribution.

Key Features

1-channel signal conditioner with 24VDC power supply
Compatible with 2-wire and 3-wire transmitters and 2-wire current sources
Signal splitter functionality (1 input and 2 outputs)
Dual output 0/4 mA...20mA with 0.1% accuracy
SIL3 certification according to IEC 61508 safety standards
Minimum field voltage of 16V at 20mA

Functional Description

This signal conditioner provides essential isolation for non-intrinsically safe applications. The device supplies power to 2-wire and 3-wire transmitters and can also interface with 2-wire current sources. It transfers the analog input signal as two isolated current values, with both outputs providing a 0/4 mA ... 20 mA current corresponding to the input signal.

The internal 250 Ω resistance between terminals 8, 9 and 11, 12 can be utilized for conversion into a 0 V ... 5 V voltage signal when required.

Technical Documentation
