KFD2-STC5-1.2O Safety Barrier PEPPERL+FUCHS SMART Transmitter Power Supply

PEPPERL+FUCHS SMART Transmitter Power Supply KFD2-STC5-1.2O

1-channel signal conditioner

24 V DC supply (Power Rail)

Input 2-wire and 3-wire SMART transmitters and 2-wire SMART

current sources

Signal splitter (1 input and 2 outputs)

Dual output 4 mA ... 20 mA current sink/current source

Terminals with test points

Up to SIL 2 (SC 3) acc. to IEC/EN 61508

Function

This signal conditioner provides the galvanic isolation between field circuits and control circuits.

The device supplies 2-wire and 3-wire SMART transmitters, and can also be used with 2-wire SMART current sources. It transfers the analog input signal to the control side as two isolated output signals.

Digital signals may be superimposed on the input signal on the field side or on the control side and are transferred bi-directionally. The device provides a sink mode or a source mode output on the control side terminals.

The device has an internal resistor. Use this resistor if the HART communication resistance in the control circuit is too low. Test sockets for the connection of HART communicators are integrated into the terminals of the device.
