KCD2-UT2-1 Pepperl Fuchs Safety Barrier Universal Temperature Converter

PEPPERL+FUCHS Universal Temperature Converter KCD2-UT2-1

< 1-channel signal conditioner

< 24 V DC supply (Power Rail)

< Thermocouple, RTD, potentiometer or voltage input

< Current output 0/4 mA ... 20 mA

< Sink or source mode

< Configurable by PACTware

< Line fault (LFD) and sensor burnout detection

< Up to SIL 2 acc. to IEC/EN 61508 / IEC/EN 61511

Function

This signal conditioner provides the galvanic isolation between field circuits and control circuits.

The device converts RTD input signals or thermocouple input signals on the field side to 0/4 mA ... 20mA signals on the control side. The removable terminal block KC-CJC-** is available for thermocouples when internal cold junction compensation is desired. A fault is indicated by an LED and by user-configured fault indication outputs.

If the device is operated via Power Rail, additionally a collective error message is available. The device is easily configured by the use of the PACTware configuration software. For additional information
