Panasonic 750W Low Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Large Image : Panasonic 750W Low Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMD082P1U

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	100pcs/month

Contact Now Chat Now

Panasonic 750W Low Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Description

Condition:

Original Brand New

Warranty:

One Year

Application:

CNC Machine, Packaging Machine, Etc.

Shipping Way:

DHL FedEx

Highlight:

Panasonic A4 Series servo motor

750W AC servo motor

Panasonic servo motor with warranty

Panasonic 750W Servo Motor MSMD082P1U | MINAS A5 Series

Product Overview

The Panasonic MSMD082P1U is a high-performance 750W AC Servo Motor from the globally trusted MINAS A5 Series. Specifically engineered for Low Inertia requirements, this motor is designed for high-cycle, high-frequency applications where rapid start-stop motion is critical. It is the industry standard for SMT assembly, high-speed packaging, and pick-and-place robotics.

Equipped with a 20-bit high-resolution encoder, a factory-installed oil seal, and a keyway shaft, the MSMD082P1U offers the perfect combination of speed, precision, and legacy compatibility for your automation systems.

Key Technical Specifications

Model Number	MSMD082P1U
Series	MINAS A5 (Low Inertia Type)
Rated Output	750 W (0.75 kW)
Voltage	200 V
Rated Torque	2.39 Nm (Peak Torque: 7.16 Nm)
Rated Speed	3000 r/min (Max Speed: 5000 r/min)
Encoder	20-bit Incremental (1,048,576 pulses/rev)
Shaft Detail	Keyway shaft with Oil Seal
Protection Rating	IP65 (Dust-proof and splash-resistant)
Inertia Type	Low Inertia (High-speed response)

Key Benefits

Ultra-High Response & Throughput

The Low Inertia design features a lightweight rotor that allows for extreme acceleration and deceleration. This minimizes cycle times in high-speed applications, significantly increasing the overall production throughput of your machinery.

Critical Legacy System Support

The MINAS A5 series remains a cornerstone in many existing production facilities. For maintenance and repair teams, the MSMD082P1U is the exact genuine replacement needed to restore machine operation without the high cost and downtime of upgrading to a newer series.

20-bit Precision Positioning

With a 20-bit optical encoder, this motor provides over 1 million pulses per revolution. This ensures ultra-smooth rotation and micro-positioning accuracy, which is essential for delicate electronic component placement and precision handling.

Industrial Durability (IP65 + Oil Seal)

The integrated oil seal and IP65 rating ensure that the motor is protected against dust and liquid splashes. This makes the MSMD082P1U highly reliable in standard industrial environments, including those with nearby machining fluids.

Ideal Applications

SMT & Electronic Assembly: Rapid-fire pick-and-place motion
Packaging Machinery: High-speed labeling, bagging, and sorting
Semiconductor Processing: Fast-cycle wafer and tray handling
Textile Machinery: High-frequency oscillating drive axes
Robotics: Small-to-medium payload, high-speed joint movement

Buy with Confidence

Condition: 100% Brand New & Original Panasonic (Factory Sealed)
Global Logistics: Fast air freight available (DHL/FedEx/UPS/TNT)
Technical Support: Expert assistance for pairing with A5 drivers (e.g., MADLT15SF)
Authenticity: Guaranteed genuine parts with full serial number tracking
