Panasonic 200W High Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Large Image : Panasonic 200W High Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MHMD022P1C

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	ship out immediately upon payment received
Payment Terms:	T/T,Western Union
Supply Ability:	100pcs/month

Contact Now Chat Now

Panasonic 200W High Inertia AC Servo Motor with 20-bit Encoder from MINAS A5 Series

Description

Condition:

Panasonic Original Brand New

Warranty:

One Year

Application:

CNC Machine, Packaging Machine, Etc.

Shipping Way:

DHL FedEx

Highlight:

Panasonic AC servo motor 200W

low inertia servo motor CNC

high response servo motor industrial automation

Panasonic 200W Servo Motor MHMD022P1C | MINAS A5 Series

Panasonic MHMD022P1C | MINAS A5 Series 200W High Inertia Servo Motor

Product Overview

The Panasonic MHMD022P1C is a precision 200W AC Servo Motor from the highly reliable MINAS A5 Series. Engineered specifically for High Inertia requirements, this motor provides superior stability and load-matching capabilities. It is the ideal solution for applications where a standard low-inertia motor might cause mechanical resonance or hunting, ensuring smooth, vibration-free motion.

Featuring a 20-bit high-resolution encoder, a round shaft, and a lead-wire connection, the MHMD022P1C is a robust, IP65-rated component designed for 24/7 industrial performance and seamless integration into existing A5-based systems.

Technical Specifications

Feature	Specification
Model Number	MHMD022P1C
Series	MINAS A5 (High Inertia Type)
Rated Output	200 W (0.2 kW)
Voltage	200 V AC
Rated Torque	0.64 Nm (Peak Torque: 1.91 Nm)
Rated Speed	3000 r/min (Max Speed: 5000 r/min)
Encoder	20-bit Incremental (1,048,576 pulses/rev)
Shaft Design	Round Shaft (Straight)
Connection Type	Lead Wire Type
Protection Rating	IP65 (Dust-proof and splash-resistant)

Key Benefits

Superior Stability & Load Matching

The High Inertia design (MHMD series) allows for a much better inertia ratio between the motor and the mechanical load. This eliminates oscillations and provides rock-solid positioning, making it perfect for belt-driven systems or loads with fluctuating mass.

High-Resolution 20-bit Feedback

Equipped with a 20-bit optical encoder, this motor delivers over 1 million pulses per revolution. This resolution allows for sub-micron accuracy, ultra-smooth rotation at low speeds, and enhanced torque ripple suppression.

Essential Legacy A5 Support

As industries maintain existing production lines, the MHMD022P1C provides a 100% compatible, genuine "drop-in" solution. Avoid the complexity and downtime of upgrading to the A6 series by using this original A5 replacement.

Rugged Industrial Build (IP65)

The IP65 rating ensures the motor is completely protected against dust ingress and low-pressure water splashes. Its compact frame and lead-wire design allow for easy installation in tight mechanical spaces where large connectors may interfere.

Primary Industrial Applications

Medical Lab Automation: Stable and quiet sample handling
Packaging Machinery: Precise labeling and synchronized conveyor feed
Electronic Assembly: Stable movement for delicate component placement
Textile Machinery: Constant-tension winding and feed control
3D Printing & Laser Engraving: Smooth axis movement for high-quality finishes

Buy with Confidence

Condition: 100% Brand New & Original Panasonic (Factory Sealed)
Global Shipping: Fast air freight options (DHL/FedEx/UPS). Same-day dispatch available
Technical Support: Expert help pairing with A5 drivers (e.g., MADLT1507)
Authenticity: Guaranteed genuine parts with full serial number tracking
