Panasonic MINAS A6 Series 200W AC Servo Motor with Low Inertia and 23-bit Encoder for Precision Control

Large Image : Panasonic MINAS A6 Series 200W AC Servo Motor with Low Inertia and 23-bit Encoder for Precision Control

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMD022P1V

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	100pcs/month

Contact Now Chat Now

Panasonic MINAS A6 Series 200W AC Servo Motor with Low Inertia and 23-bit Encoder for Precision Control

Description

Condition:

Panasonic Original Brand New

Warranty:

One Year

Application:

CNC Machine, Packaging Machine, Etc.

Shipping Way:

DHL FedEx

Highlight:

Panasonic 200W AC servo motor

AC servo motor with holding brake

Panasonic servo motor with warranty

Panasonic MINAS A6 Series MSMD022P1V 200W AC Servo Motor Kit - 23-bit Encoder, IP65 Rated

The Panasonic MSMD022P1V is a high-performance AC servo motor from the MINAS A6 Series, designed for applications requiring rapid acceleration and precise positioning. With a rated output of 200W and 200V voltage specifications, this low-inertia motor delivers exceptional responsiveness and efficiency in compact industrial automation systems.

Key Features & Benefits

Low-Inertia Design - Enables rapid acceleration and deceleration, ideal for high-cycle applications such as pick-and-place, packaging machinery, and electronic assembly equipment.
High-Resolution Incremental Encoder - Equipped with a 10000 PPR rotary encoder, providing precise positional feedback for accurate motion control.
3000 RPM Rated Speed - Delivers consistent high-speed operation, improving overall system throughput.
200W Power Output at 200V - Optimized for light-to-medium duty automation tasks, balancing power efficiency with performance.
5-Wire Configuration - Simplifies wiring and integration with control systems, reducing installation time and complexity.
Wide Ambient Temperature Range - Reliable operation between 0°C and 50°C, suitable for various industrial environments.

Technical Specifications

Parameter	Specification
Brand	Panasonic
Series	MINAS A6 Series
Part Number	MSMD022P1V
Motor Type	AC Servo Motor
Rated Output	200 W (0.2 KW)
Voltage	200 V
Rated Speed	3000 RPM
Encoder Type	Incremental Rotary Encoder
Encoder Resolution	10000 PPR
Inertia Type	Low Inertia
Ambient Temperature	0°C to 50°C
Oil Seal	Without
Wire Configuration	5-Wire Type

Typical Applications

Surface mount technology (SMT) and electronic assembly equipment
Pick-and-place machines and robotic arms
Packaging and labeling machinery
Semiconductor manufacturing equipment
CNC routers and engraving machines
Factory automation and conveyor systems

Compatible Drivers

This servo motor pairs with Panasonic MINAS A6 Series drivers for optimal performance. The motor's 23-bit absolute encoder option (depending on configuration) supports high-precision positioning without battery backup.

Why Choose the Panasonic MSMD022P1V?

Engineered for reliability and precision, the MSMD022P1V delivers consistent performance in demanding industrial environments. Its low-inertia rotor design minimizes settling time, enabling faster cycle rates and increased production output. Backed by Panasonic's MINAS A6 platform, this servo motor offers exceptional value for OEMs and system integrators seeking a dependable motion control solution.
