Panasonic MSMA042A1E 400W AC Servo Motor - MINAS A Series with 2500 PPR Encoder and Low Inertia Design

Large Image : Panasonic MSMA042A1E 400W AC Servo Motor - MINAS A Series with 2500 PPR Encoder and Low Inertia Design

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMA042A1E

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	20pcs/month

Contact Now Chat Now

Panasonic MSMA042A1E 400W AC Servo Motor - MINAS A Series with 2500 PPR Encoder and Low Inertia Design

Description

Condition:

Panasonic Original Brand New

Warranty:

One Year

Application:

CNC Machine, Packaging Machine

Shipping Way:

DHL FedEx

Highlight:

Panasonic AC servo motor 400W

A Series servo motor with warranty

Panasonic servo motor industrial automation

Panasonic MSMA042A1E 400W AC Servo Motor - MINAS A Series 3000 RPM 200V 2500 PPR Encoder

Panasonic MSMA042A1E 400W AC Servo Motor - MINAS A Series, Low Inertia, 2500 PPR Incremental Encoder

The Panasonic MSMA042A1E is a high-performance AC servo motor from the MINAS A Series, designed for applications requiring rapid acceleration and precise positioning. With a rated output of 400W and 200V AC voltage specifications, this low-inertia motor delivers exceptional responsiveness and efficiency in compact industrial automation systems.

Key Features & Benefits

Low-Inertia Design - The low-inertia rotor enables rapid acceleration and deceleration, making it ideal for high-cycle applications such as pick-and-place machines, packaging equipment, and electronic assembly systems.
2500 PPR Incremental Encoder - Equipped with a high-resolution incremental encoder providing 2500 pulses per revolution, delivering precise positional feedback for accurate motion control.
3000 RPM Rated Speed - Delivers consistent high-speed operation with maximum speed capabilities, improving overall system throughput.
400W Power Output at 200V - Optimized for light-to-medium duty automation tasks, balancing power efficiency with performance.
Vector Control Technology - Features vector control for enhanced responsiveness and smoother operation under variable loads, ensuring stable performance across different operating conditions.
Compact Footprint - With dimensions of 220mm (L) × 150mm (W) × 100mm (H) and a weight of only 1.85 kg, this servo motor is designed for easy integration into space-constrained applications.

Technical Specifications

Parameter	Specification
Brand	Panasonic
Series	MINAS A Series (MSMA Series)
Part Number	MSMA042A1E
Product Type	AC Servo Motor
Inertia Type	Low Inertia
Rated Output	400 W
Voltage	200 V AC
Rated Current	2 A
Rated Speed	3000 RPM
Maximum Speed	4500 RPM
Rated Torque	2.5 N*m
Encoder Type	Incremental Encoder
Encoder Resolution	2500 PPR
Control Method	Vector Control
Weight	1.85 kg
Dimensions (L×W×H)	220 mm × 150 mm × 100 mm
Operating Temperature	0°C - 55°C
Storage Temperature	-10°C - 75°C
Operating Humidity	10% - 90% RH (non-condensing)

Part Number Decoding (MSMA Series)

Digit	Position	Meaning	MSMA042A1E Example
1-4	Series	MSMA (Low Inertia)	MSMA
5-6	Rated Output	04 = 400W	04
7	Power Supply	2 = 200V	2
8	Specifications	A = Round shaft	A
9	Encoder	1 = 2500 PPR incremental	1
10	Additional Options	E = Standard (no brake, no oil seal)	E

Compatible Drivers

The MSMA042A1E servo motor is designed for use with Panasonic MINAS A Series drivers, specifically the MSDA Series amplifiers. Compatible driver models include:

Driver Part Number	Description
MSDA043A1A	400W compatible driver, 200V, incremental encoder input

Please verify driver compatibility with official documentation before ordering.

Typical Applications

Pick-and-Place Machines - Rapid acceleration/deceleration cycles for high-speed component placement
Packaging Machinery - Precision positioning for labeling, sealing, and cartoning equipment
Electronic Assembly - Surface mount technology (SMT) and PCB assembly systems
Small Robotics - SCARA robots and articulated arms requiring low-inertia control
CNC Engraving Machines - Precision positioning for small-format machining
Factory Automation - Conveyor systems, indexing tables, and automated workstations
Laboratory Automation - Precision fluid handling and sample processing equipment
