Panasonic MSMF152L1G6M MINAS A6 Low Inertia Servo Motor 1.5kW 200V for High-Speed Automation

Large Image : Panasonic MSMF152L1G6M MINAS A6 Low Inertia Servo Motor 1.5kW 200V for High-Speed Automation

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMF152L1G6M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MSMF152L1G6M MINAS A6 Low Inertia Servo Motor 1.5kW 200V for High-Speed Automation

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 1.5KW AC servo motor , Panasonic AC servo motor driver , 1.5KW servo motor with warranty

Panasonic MSMF152L1G6M MINAS A6 Low Inertia Servo Motor 1.5kW 200V

Panasonic MSMF152L1G6M MINAS A6 Low Inertia Servo Motor | 1.5kW, 200V

The Panasonic MSMF152L1G6M is a mid-to-high capacity AC brushless servo motor from the industry-leading MINAS A6 series. Delivering a powerful 1500W (1.5kW) output, this motor is specifically engineered with a Low Inertia rotor to facilitate extreme acceleration and high-speed response. Equipped with a high-resolution 23-bit absolute encoder and an enhanced IP67-rated enclosure with a durable oil seal, the MSMF152L1G6M provides the precision and ruggedness required for modern, high-throughput manufacturing environments.

Key Performance Advantages

Low Inertia for High Dynamics: Optimized for high-speed indexing and rapid start-stop cycles, significantly reducing overall machine cycle times and increasing OEE.
Ultra-High 23-bit Resolution: The 23-bit absolute/incremental encoder (8,388,608 pulses/rev) ensures buttery-smooth motion and sub-micron positioning accuracy.
Flagship A6 Response Bandwidth: Features a 3.2 kHz frequency response, providing instantaneous command tracking and virtually zero settling time.
Superior Environmental Protection: Rated IP67 and equipped with a high-durability oil seal, making it ideal for harsh industrial conditions involving dust, coolant, or liquid splashes.
High Power Density: Delivers a rated torque of 4.77 N*m, with a massive peak stall torque of 14.3 N*m for demanding acceleration phases.

Technical Specifications (Quick Reference)

Key Parameter	Specification
Manufacturer	Panasonic
Model Number	MSMF152L1G6M
Series	MINAS A6 (Large Capacity)
Rated Output	1500 W (1.5 kW)
Rated Torque	4.77 N*m
Peak Stall Torque	14.3 N*m
Rated Speed	3000 rpm
Maximum Speed	5000 rpm
Input Voltage	200 VAC
Encoder Type	23-bit Absolute/Incremental
Inertia Type	Low Inertia
Shaft Specification	Straight Shaft with Keyway (G-type)

MSMF152L1G6M Part Number Breakdown

Correct identification is vital for technical compatibility:

MSMF: Low Inertia Type (Large Capacity A6 Series).
15: 1.5 kW (1500W) Rated Power Output.
2: 200V AC Input Voltage.
L: 23-bit Absolute/Incremental Encoder.
1: Standard Design Sequence.
G6M: Specific technical suffix for the shaft end (with keyway), high-durability oil seal, and IP67 hardware variant.

Targeted Industrial Applications

The high-speed and rugged design of the MSMF152L1G6M make it ideal for:

Packaging Systems: Rapid labeling, high-speed bagging, and multi-axis synchronized sorting.
Textile Machinery: Precision winding, high-frequency oscillating axes, and looms.
Advanced Robotics: High-speed pick-and-place and automated material handling.
Printing & Converting: Precise tension control for high-speed printing presses.
