Panasonic MSMF302L1G6M MINAS A6 Low Inertia Servo Motor 3kW 200V

• Low Inertia for Maximum Dynamics: Optimized for high-speed indexing and extremely rapid start-stop cycles, significantly reducing overall machine cycle times and increasing productivity.
• Ultra-High 23-bit Resolution: Equipped with a 23-bit absolute/incremental encoder (8,388,608 pulses/rev) for exceptionally smooth rotation and sub-micron positioning accuracy.
• Advanced A6 Response Bandwidth: Features a 3.2 kHz frequency response, ensuring instantaneous command tracking and virtually eliminating settling times.
• Superior Environmental Protection: Rated IP67 and equipped with a high-durability oil seal, making it suitable for harsh industrial environments exposed to dust and liquid splashes.
• High Power Density: Delivers a rated torque of 9.55 N*m, with a massive peak stall torque of 28.6 N*m for heavy-duty acceleration phases.

Correct identification is vital for technical compatibility and replacement accuracy:

1. MSMF: Low Inertia Type (Large Capacity A6 Series)
2. 30: 3.0 kW (3000W) Rated Power Output
3. 2: 200V AC Input Voltage
4. L: 23-bit Absolute/Incremental Encoder
5. 1: Standard Design Sequence
6. G6M: Specific technical suffix indicating the shaft end (Straight shaft with keyway), high-durability oil seal, and IP67 hardware variant

The high-speed capabilities and 3.0kW power of the MSMF302L1G6M make it ideal for:

• High-Speed Packaging: Rapid labeling, pouching, and high-tension winding systems
• Textile Machinery: High-frequency oscillating axes and precision spinning frames
• Automated Material Handling: High-speed sorters and rapid-response gantry robots
• Advanced Printing Presses: Precise synchronization and high-speed web control
