Panasonic MSMF202L1G6M MINAS A6 AC Servo Motor 2.0kW with Low Inertia and 23-bit Absolute Encoder

The Panasonic MSMF202L1G6M is a high-performance, large-capacity AC brushless servo motor from the flagship MINAS A6 series. Delivering a powerful 2000W (2.0kW) output, this motor is specifically engineered with a Low Inertia rotor to facilitate extreme acceleration and rapid-response cycles in high-throughput automation. Equipped with an industry-leading 23-bit absolute encoder and a rugged IP67-rated construction, the MSMF202L1G6M is the premier choice for precision machinery requiring speed and environmental resilience.

• Low Inertia for High Dynamics: Optimized for high-speed indexing and rapid start-stop cycles, significantly reducing overall machine cycle times and increasing production efficiency.
• Ultra-High 23-bit Resolution: Features a 23-bit absolute/incremental encoder (8,388,608 pulses/rev) for exceptionally smooth rotation and sub-micron positioning accuracy.
• Advanced A6 Response Bandwidth: Boasts a 3.2 kHz frequency response, ensuring instantaneous command tracking and virtually zero settling time.
• Superior IP67 Environmental Protection: Fully sealed and equipped with a high-durability oil seal, making it suitable for harsh industrial environments exposed to dust, coolant, and liquid splashes.
• Robust Torque Delivery: Provides a rated torque of 6.37 N*m, with a massive peak stall torque of 19.1 N*m for demanding acceleration phases.

Correct identification is vital for technical compatibility and replacement accuracy:

1. MSMF: Low Inertia Type (Large Capacity A6 Series)
2. 20: 2.0 kW (2000W) Rated Power Output
3. 2: 200V AC Input Voltage
4. L: 23-bit Absolute/Incremental Encoder
5. 1: Standard Design Sequence
6. G6M: Specific technical suffix indicating the shaft end (with keyway), high-durability oil seal, and IP67 hardware variant

The high-speed and rugged design of the MSMF202L1G6M make it ideal for:

• High-Speed Packaging: Rapid labeling, pouching, and high-tension winding systems
• Textile Machinery: High-frequency oscillating axes and precision spinning frames
• Automated Material Handling: High-speed sorters and rapid-response gantry robots
• Advanced Printing & Converting: Precise synchronization for high-speed printing presses
