PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex2.51P

Large Image : PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex2.51P

Product Details:

Place of Origin:	Singapore
Brand Name:	PEPPERL+FUCHS
Model Number:	KFD0-CS-Ex2.51P

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex2.51P

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	PEPPERL+FUCHS safety barrier repeater , intrinsic safety barrier current driver , KFD0-CS-Ex2.51P safety repeater

PEPPERL+FUCHS Safety Barrier Current Driver Repeater KFD0-CS-Ex2.51P

Product Overview

2-channel isolated barrier designed for intrinsic safety applications with 24 V DC loop-powered operation and 0-40 mA current input/output capability.

Key Specifications

2-channel isolated barrier design
24 V DC loop-powered supply
Current input/output range: 0 mA to 40 mA
I/P or transmitter power supply capability
High accuracy: 1%
Built-in reverse polarity protection
Safety certification: Up to SIL 2 (SC 3) according to IEC/EN 61508

Functional Operation

This isolated barrier is engineered for intrinsic safety applications, transferring DC signals from fire alarms and smoke alarms from hazardous areas to non-hazardous areas. The device also supports control of I/P converters, valves, indicators, and audible alarms.

Reverse polarity protection safeguards against damage from wiring errors, while the loop-powered design eliminates the need for additional power supply connections on the control side.

Application Scenarios

Circuit Isolation: Used for isolating circuits to control positioners, I/P converters, and similar equipment. A current source is connected to terminals in the non-explosion-hazardous area.

Current Signal Isolation: Provides isolation for current signals from fire detectors and similar sensors. A voltage source connects to terminals in the non-explosion-hazardous area, with specific measurement current across passive sensors measured using a series resistor (minimum 50 Ω).
