Phoenix Contact UPS QUINT4-PS/3AC/24DC/40/IOL Power Supply 1151047

Large Image : Phoenix Contact UPS QUINT4-PS/3AC/24DC/40/IOL Power Supply 1151047

Product Details:

Place of Origin:	Thailand
Brand Name:	Phoenix Contact
Model Number:	QUINT4-PS/3AC/24DC/40/IOL

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Phoenix Contact UPS QUINT4-PS/3AC/24DC/40/IOL Power Supply 1151047

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Phoenix Contact QUINT-PS/1AC/24DC/40 , Phoenix Contact UPS , 1151047

Phoenix Contact QUINT4-PS/3AC/24DC/40/IOL - Power supply 1151047

Primary-switched power supply unit QUINT POWER, Screw connection, DIN rail mounting, input: 3-phase, output: 24 V DC / 40 A

The fourth generation of the high-performance QUINT POWER power supplies ensures superior system availability by means of new functions.
Use in all industrial networks with integrated IO-Link interface and direct connection to the QUINT UPS or the CAPAROC circuit breaker system with system integration.
The unique SFB technology and preventive function monitoring of the QUINT POWER power supply increase the availability of your application.

AC operation
Network type	Star network
Nominal input voltage range	3x 400 V AC ... 500 V AC
Nominal input voltage range	2x 400 V AC ... 500 V AC
Input voltage range	3x 400 V AC ... 500 V AC -20 % ... +10 %
Input voltage range	2x 400 V AC ... 500 V AC -10 % ... +10 %
Typical national grid voltage	400 V AC
Typical national grid voltage	480 V AC
Voltage type of supply voltage	AC
Inrush current	typ. 1.5 A (at 25 °C)
Inrush current integral (I²t)	< 0.06 A²s
Inrush current limitation	1.5 A (after 1 ms)
AC frequency range	50 Hz ... 60 Hz -10 % ... +10 %
Frequency range (f_N)	50 Hz ... 60 Hz -10 % ... +10 %
Mains buffering time	typ. 26 ms (3x 400 V AC)
Mains buffering time	typ. 26 ms (3x 480 V AC)
Current consumption	3x 1.8 A (400 V AC)
	3x 1.5 A (480 V AC)
	2x 3 A (400 V AC)
	2x 2.5 A (480 V AC)
	3x 1.5 A (500 V AC)
	2x 2.4 A (500 V AC)
Reverse polarity protection	yes
Nominal power consumption	1217 VA
Protective circuit	Transient surge protection; Varistor, gas-filled surge arrester
Power factor (cos phi)	0.95
Switch-on time	< 1 s
Typical response time	300 ms (from SLEEP MODE)
Recommended breaker for input protection	3x 4 A ... 20 A (Characteristic B, C, D, K or comparable)
Recommended fuse for input protection	≥ 300 V AC
Discharge current to PE	< 3.5 mA
Discharge current to PE	1 mA (550 V AC, 60 Hz)
DC operation
Nominal input voltage range	± 260 V DC ... 300 V DC
Input voltage range	± 260 V DC ... 300 V DC -13 % ... +30 %
Voltage type of supply voltage	DC
Current consumption	2.2 A (±260 V DC)
Current consumption	1.9 A (±300 V DC)
Nominal power consumption	1217 VA
Recommended breaker for input protection	1x 6 A (10 x 38 mm, 30 kA L/R = 2 ms)
Recommended fuse for input protection	≥ 1000 V DC

Efficiency	typ. 95.4 % (400 V AC)
Efficiency	typ. 95.4 % (480 V AC)
Nominal output voltage	24 V DC
Setting range of the output voltage (U_Set)	24 V DC ... 29.5 V DC (constant capacity)
Nominal output current (I_N)	40 A
Static Boost (I_Stat.Boost)	45 A
Dynamic Boost (I_Dyn.Boost)	60 A (5 s)
Selective Fuse Breaking (I_SFB)	215 A (15 ms)
Magnetic circuit breaker tripping	A1...A40 / B2...B25 / C1...C13 / Z1...Z16
Derating	> 60 °C ... 70 °C (2.5 %/K)
Feedback voltage resistance	≤ 35 V DC
Protection against overvoltage at the output (OVP)	≤ 32 V DC
Control deviation	< 0.5 % (Static load change 10 % ... 90 %)
	< 3 % (Dynamic load change 10 % ... 90 %, (10 Hz))
	< 0.25 % (change in input voltage ±10 %)
Residual ripple	< 50 mV_PP (with nominal values)
Short-circuit-proof	yes
No-load proof	yes
Output power	960 W
	1080 W
	1440 W
Maximum no-load power dissipation	< 5 W (400 V AC)
Maximum no-load power dissipation	< 5 W (480 V AC)
Power loss nominal load max.	< 45 W (400 V AC)
Power loss nominal load max.	< 45 W (480 V AC)
Power dissipation SLEEP MODE	< 2 W (400 V AC)
Power dissipation SLEEP MODE	< 2 W (480 V AC)
Crest factor	typ. 1.6 (400 V AC)
Crest factor	typ. 1.9 (480 V AC)
Rise time	< 1 s (U_Out = 10 % ... 90 %)
Connection in parallel	yes, for redundancy and increased capacity
Connection in series	yes
Fuse protection (secondary side)	electronic
	thermal-magnetic
	thermal
Signal relay 13/14 (configurable)
Default	closed (U_out > 0.9 U_Set)
Digital	24 V DC 1 A
Digital	30 V AC/DC 0.5 A
