Panasonic MSMA202P1G MINAS A4 Servo Motor 2kW 200V Low Inertia IP65, 2500 P/r Incremental Encoder 3000 RPM for Packaging Machine

Large Image : Panasonic MSMA202P1G MINAS A4 Servo Motor 2kW 200V Low Inertia IP65, 2500 P/r Incremental Encoder 3000 RPM for Packaging Machine

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMA202P1G

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	ship out immediately upon payment received
Payment Terms:	T/T,Western Union
Supply Ability:	50pcs/month

Contact Now Chat Now

Panasonic MSMA202P1G MINAS A4 Servo Motor 2kW 200V Low Inertia IP65, 2500 P/r Incremental Encoder 3000 RPM for Packaging Machine

Description

Condition:

Panasonic Original Brand New

Warranty:

One Year

Application:

CNC Machine, Packaging Machine

Shipping Way:

DHL FedEx

Highlight:

Panasonic AC servo motor 2KW

2KW servo motor for packaging

AC servo motor with warranty

Panasonic MSMA202P1G MINAS A4 Servo Motor

Product Overview

The Panasonic MSMA202P1G is a high-performance AC servo motor from the industry-leading MINAS A4 Family. Engineered as a low inertia servo motor with IP65 environmental protection, this 2kW (2000W) model delivers exceptional speed response, high torque density, and precise motion control for demanding industrial automation applications.

Part of Panasonic's widely adopted MINAS A4 series, the MSMA202P1G features a 2500 P/r incremental encoder that provides precise position and speed feedback for closed-loop motion control systems. The motor is designed with a key-way shaft, oil seal, and connector-type lead-out configuration, making it suitable for high-speed applications requiring rapid acceleration and deceleration.

Key Features

Genuine Panasonic MINAS A4 - 100% authentic, brand new original product
Low Inertia Design - 3.46 × 10⁻⁴ kg*m² rotor inertia for high-speed response
High Speed Capability - 3000 rpm rated speed, 5000 rpm maximum speed
IP65 Protection Rating - Dust-tight and protected against water jets
High Torque Density - 6.36 Nm rated torque, 19.1 Nm peak torque (300% overload)
2500 P/r Incremental Encoder - High-resolution feedback for precise positioning
Key-way Shaft with Oil Seal - Reliable torque transmission and contamination protection
Unlimited Regenerative Brake Frequency - No limit with or without external resistor
International Safety Approvals - CE, CSA, cULus, TUV, UL certified
Ready for Immediate Shipment - Global stock available

Technical Specifications

Parameter	Specification
Manufacturer	Panasonic Industrial Automation Sales
Series	MINAS A4 Family
Model	MSMA202P1G
Product Type	AC Servo Motor
Rated Output Power	2 kW (2000 W)
Voltage Specifications	200 V AC
Rated Torque	6.36 N*m (900.65 oz-in)
Peak Torque	19.1 N*m (2700 oz-in)
Rated Rotational Speed	3000 r/min
Maximum Rotational Speed	5000 r/min
Moment of Inertia (Rotor)	3.46 × 10⁻⁴ kg*m²
Encoder	2500 P/r Incremental system
Protection Class	IP65
Shaft	Key-way
Weight	6.5 kg (14.3 lbs)
Approvals	CE, CSA, cULus, TUV, UL

Product Features & Benefits

Low Inertia Design for High-Speed Response

The MSMA202P1G features a low inertia rotor (3.46 × 10⁻⁴ kg*m²) specifically designed for applications requiring rapid acceleration and deceleration. The low inertia design enables fast response times for high-speed positioning and excellent performance in pick-and-place applications.

High Speed Capability

With a rated speed of 3000 rpm and maximum speed of 5000 rpm, this motor is ideal for high-speed applications requiring rapid motion cycles.

IP65 Environmental Protection

With an IP65 protection rating, this motor is built to withstand harsh industrial environments with complete protection against dust ingress and protection against water jets from any direction.

Note: The IP65 rating applies to the motor body. The rotating portion of the output shaft and the connecting pin parts of the motor connector and the encoder connector are excluded from this rating.

High Torque Output with 300% Overload Capacity

The MSMA202P1G delivers impressive torque characteristics with 6.36 N*m rated torque for continuous operation and 19.1 N*m peak torque (300% of rated torque), enabling rapid acceleration and high dynamic response.

Applications

High-Speed Pick-and-Place

PCB assembly machines, electronic component placement, semiconductor handlers

Packaging Machinery

High-speed filling machines, labeling systems, cartoning equipment, sealing machines

Robotics

SCARA robots, delta robots, high-speed articulated arms, pick-and-place systems

Machine Tools

CNC routers, engraving machines, high-speed milling spindles, positioning tables

Semiconductor Equipment

Wafer handling systems, die bonders, wire bonders, inspection equipment

Printing & Converting

Web handling systems, registration control, cutting and slitting equipment

Compatible Servo Amplifiers

The MSMA202P1G is a common item for A4 Series/AIII Series systems, providing flexibility for system integration and replacement applications.

Servo Amplifier Series	Description
MINAS A4 Series	Optimal compatibility, same generation
MINAS AIII Series	Compatible as common item

Ordering Information

Ready to order or need technical assistance? Contact our sales team today for best pricing, volume discount quotations, lead time confirmation, and installation support.

Minimum Order Quantity: 1 piece
Sample Availability: Yes - sample orders accepted
Bulk Pricing: Available for orders of 5+ units
Warranty: 12-month warranty against manufacturing defects
