Yaskawa Servo Motor for CNC machine SGM7J-04AFC61 Sigma-7 Servo Motor 400W 24-bit Incremental Encoder IP67 Rated for Industrial Automation

Large Image : Yaskawa Servo Motor for CNC machine SGM7J-04AFC61 Sigma-7 Servo Motor 400W 24-bit Incremental Encoder IP67 Rated for Industrial Automation

Product Details:

Place of Origin:	Japan
Brand Name:	Yaskawa
Model Number:	SGM7J-04AFC61

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	200pcs/month

Contact Now Chat Now

Yaskawa Servo Motor for CNC machine SGM7J-04AFC61 Sigma-7 Servo Motor 400W 24-bit Incremental Encoder IP67 Rated for Industrial Automation

Description

Condition:

Original Brand New

Warranty:

One Year

Shipping Way:

DHL FedEx

Application:

Automation Industry

Highlight:

Yaskawa 400W servo motor with brake

AC servo motor with brake

SGM7J-04AFC61 servo motor

Yaskawa Servo Motor for CNC machine SGM7J-04AFC61 Sigma-7 Servo Motor 400W 24-bit Incremental Encoder IP67 Rated for Industrial Automation

Product Overview

SGM7J‑04AFC61 is a 400W medium‑inertia rotary AC servo motor from Yaskawa's flagship Sigma‑7 Series, engineered for high‑precision motion control in compact industrial automation systems. It features a 24‑bit incremental encoder, IP67 protection, and SIL 3 safety rating, delivering exceptional responsiveness, accuracy, and reliability.

Parameter	Value
Model	SGM7J‑04AFC61
Series	Sigma‑7 (SGM7J)
Rated Power	0.4 kW (400W)
Supply Voltage	200 VAC
Rated Torque	1.27 N*m
Peak Torque	4.46 N*m (350% of rated)
Rated Speed	3,000 rpm
Max Speed	6,000 rpm
Encoder	24‑bit incremental (16Mppr)
Inertia	0.486 × 10⁻⁴ kg*m²
Dimensions (W × H × D)	60 × 74.7 × 115.5 mm
Weight	1.1 kg
Protection	IP67 (dust‑tight & water‑washdown resistant)
Safety	SIL 3 (IEC 61508)
Matching Drive	SGD7S‑2R8A series

Key Features & Advantages

Ultra‑High Precision - 24‑bit high‑resolution encoder ensures industry‑leading positional accuracy and repeatability. Ultra‑low cogging torque for smooth, vibration‑free motion at low speeds.
Superior Dynamic Performance - 350% peak torque (4.46 N*m) for rapid acceleration/deceleration. Fast response ideal for high‑duty, high‑cycle applications. 6,000 rpm max speed for high‑throughput operations.
Compact & Efficient Design - 20% smaller footprint than previous‑generation motors. Flange‑compatible with Sigma‑5 for easy retrofitting. High‑efficiency neodymium magnets reduce heat generation by 20%.
Rugged & Reliable - IP67 rating withstands harsh industrial environments (dust, coolant, washdown). SIL 3 safety certification for machine safety compliance. Operates up to 60 °C and altitudes >2,000 ft.

Ideal Applications

CNC machinery (routers, mills, lathes)
Packaging & labeling equipment
Semiconductor manufacturing
Robotic arms & pick‑and‑place systems
Printing & textile machinery
Medical devices & precision automation

Industry	Typical Applications
Packaging Machinery	High-speed filling, sealing, labeling, and cartoning equipment
Semiconductor Equipment	Wafer handling, inspection systems, die bonders, wire bonders
PCB Assembly	Pick-and-place machines, screen printers, component inserters
Robotics	SCARA robots, articulated robots, collaborative robots
Machine Tools	Feed axes, positioning tables, CNC machining centers
Automated Assembly	Component insertion, fastening, and testing systems
Printing & Converting	Web handling, registration control, cutting systems
Food Processing	Washdown-compatible applications
Medical Equipment	Diagnostic systems, laboratory automation
Electronic Manufacturing	Test handlers, inspection systems, placement equipment

Compatible Servo Amplifiers (SERVOPACKs)

The SGM7J-04AFC61 is designed for seamless integration with Yaskawa Sigma-7 SERVOPACKs:

SERVOPACK Model	Description
SGD7S-2R8A	Single-axis, 200V, suitable for 400W motor
SGD7W-2R8A	Dual-axis compact design, 200V
SGD7W-5R5A	Dual-axis, higher current capacity
SGD7W-7R6A	Dual-axis, maximum current capacity

Backward Compatibility: This motor is flange-compatible with Sigma-5 installations, simplifying upgrades. For detailed transition guidance, refer to Yaskawa's Sigma-5 to Sigma-7 Transition Guide.

Model Number Reference

The SGM7J-04AFC61 belongs to the SGM7J series with the following configuration:

Code Segment	Description
SGM7J	Sigma-7 Series, Medium Inertia, Rotary Servo Motor
04	400W (0.4 kW) Rated Output
A	200V Power Supply
F	Incremental Encoder (24-bit)
C	Shaft Configuration (with key and tap)
61	Option Code (without brake, specific connector configuration)
