Tamagawa TS5013N60 Incremental Encoder with 5000 PPR Square Hollow Shaft and A/B/Z Output

Large Image : Tamagawa TS5013N60 Incremental Encoder with 5000 PPR Square Hollow Shaft and A/B/Z Output

Product Details:

Place of Origin:	Japan
Brand Name:	Tamagawa
Certification:	CE UL ROSH
Model Number:	TS5013N60

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	tamagawa original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	50pcs/month

Contact Now Chat Now

Tamagawa TS5013N60 Incremental Encoder with 5000 PPR Square Hollow Shaft and A/B/Z Output

Description

Condition:

Tamagawa Original Brand New

Warranty:

One Year

Application:

Automation Industry

Shipping Way:

DHL FedEx

Highlight:

Tamagawa rotary encoder TS5013N60

Tamagawa encoder with warranty

TS5013N60 industrial rotary encoder

Tamagawa TS5013N60 Incremental Encoder OIS68 Series

Product Overview

The Tamagawa TS5013N60 (also known as OIS 80‑2048C/T‑L3‑12V) is a high-precision incremental optical rotary encoder manufactured by Tamagawa Seiki Co., Ltd. (Japan). Designed for high-performance motion control, position feedback, and velocity measurement in industrial automation and servo systems.

Specifications

Parameter	Value
Model	TS5013N60 / OIS 80‑2048C/T‑L3‑12V
Type	Incremental Optical Rotary Encoder
Resolution	2048 pulses per revolution (2048 C/T)
Supply Voltage	DC 12V
Output Type	Line driver (differential) output (A, B, Z phases)
Max. Rotational Speed	5,000 rpm
Protection Rating	IP52 (dust-protected, limited water ingress)
Operating Temperature	-20°C to +85°C
Storage Temperature	-30°C to +85°C
Weight	Approx. 1.5-2.0 kg
Shaft Type	Solid shaft (standard for servo motor integration)
Applications	Servo motors, CNC machines, robotics, elevators, industrial automation

Key Features & Benefits

High Precision & Stability: 2048-count resolution delivers accurate position and speed feedback for closed-loop control
Optical Sensing: Non-contact optical technology ensures long service life, low wear, and high reliability
Robust Build: IP52 protection and wide temperature range enable operation in harsh industrial environments
Easy Integration: Standard solid-shaft design and line-driver output simplify installation with servo drives and PLCs
Tamagawa Quality: Built to Japanese industrial standards for durability and consistent performance

Typical Applications

Servo Motor Systems: Primary feedback device for AC/DC servo motors in automation
CNC Machinery: Precise axis positioning for milling, lathes, and grinding machines
Industrial Robots: Joint angle and end-effector position control
Elevator & Escalator: Speed regulation and floor positioning
Packaging & Textile Machinery: High-speed motion control and synchronization

Why Choose TS5013N60 for Your Project?

Proven Reliability: Trusted in thousands of industrial installations worldwide
Plug-and-Play Compatibility: Direct replacement for many legacy encoders in servo systems
Long-Term Availability: Supported by Tamagawa's global distribution and service network
Cost-Effective Performance: Balances high precision with competitive pricing for industrial OEMs

Ordering & Support

Condition: New, original genuine Tamagawa product
Packaging: Standard industrial box
Lead Time: Typically 2-7 days for in-stock items; negotiable for bulk orders
Support: Includes datasheet, wiring diagram, and installation dimensions upon request
