Delta ECMA-C20807SS 750W Servo Motor 220V 3000rpm In Stock for Industrial Automation

Large Image : Delta ECMA-C20807SS 750W Servo Motor 220V 3000rpm In Stock for Industrial Automation

Product Details:

Place of Origin:	Taiwan
Brand Name:	Delta
Certification:	CE UL
Model Number:	ECMA-C20807SS

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiable
Packaging Details:	Delta original package
Delivery Time:	In stock
Payment Terms:	T/T,Western Union
Supply Ability:	200pcs/month

Contact Now Chat Now

Delta ECMA-C20807SS 750W Servo Motor 220V 3000rpm In Stock for Industrial Automation

Description

Condition:

Delta Original Brand New

Warranty:

One Year

Shipping Way:

DHL FedEx

Application:

Packaging Machine, Cnc Machine Etc.

Highlight:

750W AC servo motor

Delta ECMA-C20807SS servo motor

AC servo motor with warranty

Delta ECMA-C20807SS 750W Servo Motor

A high-precision 750W low-inertia AC servo motor from the ASDA-B2 series, designed for demanding industrial automation applications with 220V input and 3000rpm rated speed.

Product Overview

The Delta ECMA-C20807SS is engineered for high-precision motion control applications. Featuring a 17-bit incremental encoder (160,000 p/rev) and integrated holding brake, this motor is ideal for vertical axis applications requiring position holding when power is off. The shaft includes both keyway and oil seal for secure torque transmission and protection against oil ingress.

Technical Specifications

Parameter	Specification
Model	ECMA-C20807SS
Series	ASDA-B2 Series / ECMA-B2 Low Inertia Series
Output Power	750 W (0.75 kW)
Rated Speed	3000 rpm
Rated Torque	2.39 N*m (338.5 oz-in)
Peak Torque	7.16 N*m (1014 oz-in)
Input Voltage	200-230V AC, Single Phase / Three Phase
Continuous Output Current	5.10 Arms
Peak Output Current	15.30 Arms
Encoder Type	17-bit Incremental (160,000 p/rev)
Frame Size	80 mm x 80 mm (3.150" x 3.150")
Shaft Diameter	19 mm (0.748")
Shaft Type	Keyway with Oil Seal
Brake	Integrated Holding Brake (24V DC)
Inertia Type	Low Inertia
Protection Rating	IP65
Termination	Cable with Connector
Operating Temperature	0°C ~ 40°C
Storage Temperature	-10°C ~ 80°C
Certifications	CE, cURus, RoHS

Key Features

High Precision Positioning

17-bit high-resolution incremental encoder (160,000 pulses per revolution)
10-pole rotor magnetics for reduced cogging torque

Integrated Holding Brake

Built-in 24V DC holding brake for vertical axis applications
Position holding during power loss

Robust Mechanical Design

Shaft with keyway for secure torque transmission
Oil seal protection against ingress
IP65 protection rating

Low Inertia Design

Rapid acceleration and deceleration
Maximum torque up to 300% of rated

Plug-and-Play Compatibility

Designed to pair with Delta ASD-B2-0721-B servo drive
Auto-identification for quick setup

Durable Construction

High-quality Neodymium-Iron-Boron magnets
Segmented stator design for improved efficiency
Withstands 2.5Gs of vibration

Model Number Breakdown

Code	Position	Meaning
ECMA	Prefix	Electric Commutated Motor (Delta Servo Motor)
C	Series Code	220V / 3000 rpm
2	Encoder Type	17-bit Incremental
08	Frame Size	80 mm
07	Output Power	750W
S	Shaft Type	Keyway with Oil Seal
S	Brake/Termination	With Brake / Standard Connector

Applications

Industry	Application Examples
CNC Machinery	Milling machines, engraving machines, tool changers
Robotics	Articulated arms, pick-and-place systems, SCARA robots
Packaging	Fillers, sealers, labeling machines, cutters
Textile	Winding machines, looms, embroidery equipment
Printing	High-precision registration systems, printing presses
General Automation	Conveyors, feeders, dispensing machines, cutting machines
Material Handling	Automated guided vehicles (AGVs), vertical axis conveyors

Matching Drive

The ECMA-C20807SS is designed to pair with Delta ASDA-B2 series servo drives:

Drive Model	Power	Communication	Description
ASD-B2-0721-B	750W	Pulse / RS-485	Standard model for general automation
ASD-B2-0721-F	750W	CANopen	For networked multi-axis systems

Drive Features:

Supports 17-bit encoder interface
Built-in position, speed, and torque control modes
Auto-tuning and vibration suppression functions
Modbus communication (RS-485/RS-232)

Key Benefits

Benefit	Description
High Precision	17-bit encoder provides exceptional positioning accuracy
Safe Vertical Hold	Integrated brake ensures position holding on vertical axes
Reliable Operation	IP65 rating and oil seal ensure durability in harsh environments
Easy Integration	Plug-and-play compatibility with Delta B2 series drives
Secure Torque Transmission	Keyway shaft prevents slippage under load
Quick Response	Low inertia design enables rapid acceleration/deceleration
Proven Performance	Widely used in industrial automation worldwide

Certifications & Compliance

CE certified - complies with European safety standards
cURus certified - recognized for North American markets
RoHS compliant - environmentally friendly manufacturing
IP65 - dust-tight and water jet protected

Ordering Information

Item	Details
Manufacturer	Delta Electronics, Inc.
Part Number	ECMA-C20807SS
Part Status	Obsolete / End of Life - verify availability before ordering
Packaging	Factory sealed box
Country of Origin	Taiwan, China
Weight	Approx. 5.0 kg

Need Support?

Technical specifications and datasheets
Volume pricing and availability (while stocks last)
Matching drive (ASD-B2-0721-B)
Cable and accessory recommendations
