Eaton MTL TP48 35V 10kA Surge Current 316 Stainless Steel Surge Protector for Hazardous Areas

Large Image : Eaton MTL TP48 35V 10kA Surge Current 316 Stainless Steel Surge Protector for Hazardous Areas

Product Details:

Place of Origin:	India
Brand Name:	MTL
Model Number:	TP48-3-I-NDI

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	ship out immediately after payment received
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Eaton MTL TP48 35V 10kA Surge Current 316 Stainless Steel Surge Protector for Hazardous Areas

Description

Condition:	Original Brand New	Warranty:	One Year
Series:	Eaton Crouse-Hinds Series	Shipping Way:	DHL FedEx Express
Application:	Automation Industries, Oil, Gas, Chemical Industries	Certificate:	CE ISO TUV
Highlight:	316 Stainless Steel Surge Arrestor , TP48 Surge Protector 35V , TP48-3-I-NDI

Eaton MTL TP48 Surge Protector

Eaton Crouse-Hinds series MTL TP48 surge protector, 35V, 10kA surge current, 316 stainless steel construction, <76V protection level, featuring 4 flying leads (+ve, -ve, signal and earth), 18 AWG, 20mm ISO thread, with comprehensive certifications for hazardous environments.

Product Specifications

Catalog Number	TP48-3-I-NDI
Product Type	Surge Protector
Dimensions	75mm (L) × 27mm (H) × 23mm (W)
Weight	175g
Material	316 Stainless Steel
Thread Size	20mm ISO
Connection Details	4 flying leads (+ve, -ve, signal and earth)
Conductor Cross-section	18 AWG

Electrical Specifications

Nominal Voltage DC	35V
Max. Continuous Voltage DC	58V
Nominal Discharge Surge Current (8/20)	10 kA
Lightning Impulse Current (10/350 µs)	2.5 kA
Voltage Protection Level at In	90V
Voltage Protection Level at 1kV/µS	<76V
Max. Leakage Current	<1μA
Frequency	1 MHz

Environmental & Safety Ratings

Area Classification	Hazardous/Classified Locations
IECEx/ATEX Hazardous Rating	Zone 2
Ingress Protection (IP) Rating	IP66
Operating Temperature	-40°C to 60°C
Storage Temperature	-40°C to 85°C
Humidity	5-95% RH (non-condensing)
Category Tested Acc. IEC 61643-21	A2, B2, C1, C2, C3, D1
Standards Compliance	IEC, NEC/CEC, IECEx/ATEX, IEC 61508, IEC 61511

MTL TP48 Surge Protection for 2, 3 & 4 Wire Transmitters

The Crouse-Hinds series MTL TP48 surge protection device provides critical protection for field-mounted process transmitters at the point of installation. Designed for simple integration, the TP48 screws directly into unused conduit entries without requiring additional modifications.

Safeguards electronic process transmitters against induced surges and transients from field cabling
Automatic reset functionality after each operation
Available with screw threads to suit different transmitters
Explosion-proof and intrinsically safe options for hazardous areas
Maximum working voltage of 48V DC with impulse ratings of 10kA peak current and 10kV peak voltage
Approvals for intrinsically safe, flameproof, explosion-proof and non-incendive operation
Compatible with all gas groups and apparatus temperature classifications up to T6
Functional Safety applications compliant with IEC 61508 and IEC 61511 standards

Available Variants

TP48-N-NDI
TP48-I-NDI
TP48-G-NDI
TP48-3-N-NDI
TP48-3-I-NDI
TP48-3-G-NDI
TP48-4-N-NDI
TP48-4-I-NDI
TP48-4-G-NDI
