Panasonic MHMF012L1V2M 100W High Inertia AC Servo Motor with 23-bit Encoder and IP67 Rating

Large Image : Panasonic MHMF012L1V2M 100W High Inertia AC Servo Motor with 23-bit Encoder and IP67 Rating

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MHMF012L1V2M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MHMF012L1V2M 100W High Inertia AC Servo Motor with 23-bit Encoder and IP67 Rating

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic Servo Motor 100W , IP65 Panasonic Servo Motor , MHMF012L1V2M

Panasonic MHMF012L1V2M | MINAS A6 Series 100W High Inertia Servo Motor

The Panasonic MHMF012L1V2M is a high-performance AC Servo Motor from the cutting-edge MINAS A6 Series. Designed specifically for High Inertia requirements, this 100W motor provides rock-solid stability for small-scale automation applications with fluctuating loads or mechanical resonance, ensuring precise positioning without hunting effect.

Key Technical Specifications

Model Number: MHMF012L1V2M
Series: MINAS A6 (Small Type)
Rated Output: 100 W (0.1 kW)
Voltage: 200 V
Inertia Type: High Inertia (Superior load matching)
Rated Torque: 0.32 N·m (Peak Torque: 0.95 N·m)
Rated Speed: 3000 r/min (Max Speed: 6500 r/min)
Encoder: 23-bit Absolute/Incremental (8,388,608 pulses/rev)
Protection Rating: IP67 (Dust-tight and waterproof)
Shaft Detail: Keyway shaft with Oil Seal

Key Advantages

Unmatched Motion Stability: High Inertia design provides better inertia match between motor and load, reducing mechanical vibration and shortening settling times.

Ultra-High Precision (23-bit): Advanced 23-bit optical encoder delivers over 8 million pulses per revolution for sub-micron accuracy and smooth low-speed rotation.

Rugged Industrial Build (IP67): Completely protected against dust and water jets with integrated oil seal for protection against industrial coolants and lubricants.

Compact & Efficient: A6 series optimized to be up to 30% smaller than previous generations with high power-to-size ratio.

Ideal Applications

Medical Lab Automation: Ultra-precise liquid handling and sample sorting
Electronic Assembly: High-speed pick-and-place and SMT equipment
Semiconductor Tools: Stable wafer handling in cleanroom environments
3D Printing & Laser Cutting: Smooth axis movement for superior finish quality
Packaging Machinery: Precise labeling and film feeding

Detailed Specifications

Parameter	Specification
Part Number	MHMF012L1V2M
Family Name	MINAS A6
Series	MHMF Series
Type	High inertia
Protection Class	IP65 (IP67 for rotating portion)
Flange Size	40 mm sq.
Motor Lead Configuration	Lead wire
Power Supply Capacity	0.5 kVA
Rated Current	1.1 A rms
Holding Brake	Included
Mass	0.64 kg
Oil Seal	Included
Shaft Type	Key-way, center tap
Continuous Stall Torque	0.33 N·m
Momentary Max. Peak Torque	1.11 N·m
Max. Current	5.5 A 0-p
Inertia of Rotor	0.074 × 10⁻⁴ kg·m²
Recommended Inertia Ratio	30 times or less
Rotary Encoder Resolution	8,388,608

Brake Specifications

Parameter	Specification
Static Friction Torque	0.38 N·m or more
Engaging Time	35 ms or less
Releasing Time	20 ms or less
Exciting Current	0.30 A DC
Exciting Voltage	24 ± 2.4 V DC

This brake will be released when energized. Do not use for braking the motor in motion.

Permissible Load Specifications

Condition	Radial Load (P-direction)	Thrust Load (A/B-direction)
During Assembly	147 N	88 N / 117.6 N
During Operation	68.6 N	58.8 N

Purchase Information

Condition: 100% Brand New & Original Panasonic (Factory Sealed)
Global Shipping: Fast air freight options available worldwide
Technical Support: Expert guidance for driver pairing
Authenticity: Guaranteed genuine parts with full serial number tracking
