Panasonic MINAS A6 Series 200W High Inertia Servo Motor with IP67 Protection

Large Image : Panasonic MINAS A6 Series 200W High Inertia Servo Motor with IP67 Protection

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MHMF022L1V2M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original brand new
Delivery Time:	3 working days
Payment Terms:	T/T
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MINAS A6 Series 200W High Inertia Servo Motor with IP67 Protection

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic AC Servo Motor MINAS A6 , 200W Panasonic AC Servo Motor , MHMF022L1V2M

Panasonic MINAS A6 MHMF022L1V2M 200V 200W Keyway Shaft Motor

Product Overview

The MHMF022L1V2M represents the cutting edge of Panasonic's motion control technology. As part of the MINAS A6 Series, this 200W motor is specifically engineered for "High Inertia" applications. It provides superior control stability for machinery with fluctuating loads, ensuring smooth operation where low-inertia motors might struggle with resonance.

Equipped with a high-durability oil seal and a 23-bit absolute encoder, it is built for both extreme precision and harsh industrial environments.

Key Technical Specifications

Model: MHMF022L1V2M
Series: MINAS A6 High Inertia (Small Type)
Rated Output: 200 W
Voltage: 200 V
Rated Torque: 0.64 N*m (Peak Torque: 1.91 N*m)
Rated Speed: 3000 r/min (Max Speed: 6500 r/min)
Encoder: 23-bit (8,388,608 pulses per revolution)
Shaft Specification: Keyway shaft
Environmental Protection: IP67 (Dust-tight and Water immersion resistant)
Oil Seal: Included (With protective lip)

Key Advantages

High Inertia for Superior Stability
Unlike standard motors, the high-inertia design of the MHMF series allows for much better matching with mechanical loads. This reduces "hunting" and vibration, leading to shorter settling times and higher machine throughput.

Advanced 23-bit Encoder Technology
Achieve sub-micron accuracy with the integrated 23-bit optical encoder. This high resolution ensures exceptionally smooth rotation at low speeds and ultra-precise positioning for high-end automation.

Industrial-Grade Durability (IP67)
Designed for the "real world," this motor is rated IP67. It is fully protected against dust ingress and can withstand powerful water jets or temporary immersion, making it ideal for food processing, machine tools, and oily environments.

Compact "A6" Form Factor
Panasonic has reduced the weight and size of the A6 series by up to 30% compared to previous generations, allowing you to build smaller, more efficient control cabinets and machines.

Ideal Applications

High-Precision Packaging

Conveyor Systems

Machine Tool Feed Axes

Automated Assembly

Detailed Specifications

Item	Specifications
Part Number	MHMF022L1V2M
Family Name	MINAS A6
Series	MHMF Series
Type	High inertia
Protection class	IP65
Flange size (mm)	60
Motor lead-out configuration	Lead wire
Voltage specifications (V)	200
Rated output (W)	200
Rated current [Reference value] (A rms)	1.4
Holding brake	with
Mass (kg)	1.2
Oil seal	with
Shaft	Key-way, center tap
Rated torque (N ⋅ m)	0.64
Continuous stall torque (N ⋅ m)	0.76
Momentary Max. peak torque (N ⋅ m)	2.23
Max. current [Reference value] (A 0-p)	6.9
Rated rotational speed (r/min)	3000
Max. rotational speed (r/min)	6500
Inertia of rotor ( x10-4 kg ⋅ m²)	0.31
Recommended inertia ratio	30 times or less
Rotary encoder: specifications	23-bit Absolute/Incremental system
Rotary encoder: Resolution	8388608

Brake Specifications

Item	Specifications
Static friction torque (N ⋅ m)	1.6 or more
Engaging time (ms)	50 or less
Releasing time (ms)	20 or less
Exciting current (DC) (A)	0.36
Releasing voltage (DC) (V)	1 or more
Exciting voltage (DC) (V)	24 ± 2.4

Important: This brake will be released when it is energized. Do not use this for braking the motor in motion.

Permissible Load

Item	Specifications
During assembly: Radial load P-direction (N)	392
During assembly: Thrust load A-direction (N)	147
During assembly: Thrust load B-direction (N)	196
During operation: Radial load P-direction (N)	245
During operation: Thrust load A, B-direction (N)	98

Compatible Drivers

Part Number	Series	Type	I/F Classification	Frame	Supply Voltage
MADLN15NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	A-Frame	Single/3-phase 200 V
MADLN15SE	A6SE series	Position control type	Pulse train only	A-Frame	Single/3-phase 200 V
MADLN15SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485 /RS232)	A-Frame	Single/3-phase 200 V
MADLT15NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	A-Frame	Single/3-phase 200 V
MADLT15SF	A6SF series	Multifunction type	Analog /Pulse, Modbus (RS485 /RS232)	A-Frame	Single/3-phase 200 V

Note: Specifications and design of the products are subject to change without notice for product improvement.
