Single / 3 Phase Panasonic AC Servo Motor 200W Low Inertia MSMF022L1V2M

Large Image : Single / 3 Phase Panasonic AC Servo Motor 200W Low Inertia MSMF022L1V2M

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMF022L1V2M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Single / 3 Phase Panasonic AC Servo Motor 200W Low Inertia MSMF022L1V2M

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	3 Phase Panasonic AC Servo Motor , Panasonic AC Servo Motor 200W , MSMF022L1V2M

Panasonic AC Servo Motor 200W Low Inertia MSMF022L1V2M

Product Overview

Part Number	MSMF022L1V2M
Product Family	MINAS A6 Family Servo Motor
Type	Low inertia, Lead wire type

Key Features

Power range: 50 W to 22 kW
Input power supply: DC 24 V/48 V or AC 100 V/200 V/400 V
23-bit Absolute/Incremental encoder (battery-less option available)
High frequency response: 3.2 kHz
IP65 protection rating
Built-in holding brake

Technical Specifications

Motor Specifications

Rated Output	200 W
Rated Torque	0.64 N⋅m
Max. Peak Torque	1.91 N⋅m
Rated Speed	3000 r/min
Max. Speed	6000 r/min
Rated Current	1.5 A rms
Rotor Inertia	0.17 × 10⁻⁴ kg⋅m²
Mass	1.3 kg
Flange Size	60 mm sq.

Brake Specifications

Static Friction Torque	1.27 N⋅m or more
Engaging Time	50 ms or less
Releasing Time	15 ms or less
Exciting Voltage	24 ± 1.2 V DC

Important: This brake releases when energized. Do not use for braking the motor in motion.

Permissible Load

During Assembly - Radial Load	392 N
During Assembly - Thrust Load A	147 N
During Assembly - Thrust Load B	196 N
During Operation - Radial Load	245 N
During Operation - Thrust Load	98.0 N

Compatible Drivers

Specifications and design are subject to change without notice for product improvement.

Part Number	Series	Type	Interface	Frame	Supply Voltage
MADLN15NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	A-Frame	Single/3-phase 200 V
MADLN15SE	A6SE series	Position control type	Pulse train only	A-Frame	Single/3-phase 200 V
MADLN15SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485/RS232)	A-Frame	Single/3-phase 200 V
MADLT15NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	A-Frame	Single/3-phase 200 V
MADLT15SF	A6SF series	Multifunction type	Analog/Pulse, Modbus (RS485/RS232)	A-Frame	Single/3-phase 200 V

Special Order Notice: Please avoid distributing this motor, or equipment containing this motor, to Japan or other regions through Japan.
