MSMF082L1V2M Panasonic 750W AC Servo Motor

Large Image : MSMF082L1V2M Panasonic 750W AC Servo Motor

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMF082L1V2M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MSMF082L1V2M Panasonic 750W AC Servo Motor

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 750W AC servo motor , Panasonic AC servo motor driver , 750W servo motor with warranty

MSMF082L1V2M Panasonic 750W AC Servo Motor

Product Overview

Part Number	MSMF082L1V2M
Product Type	Servo Motor
Product Family	MINAS A6 Family Servo Motor
Design	Low inertia, Lead wire type

Key Features

Power range: 50 W to 22 kW
Input power supply for Driver: DC 24 V/48 V or AC 100 V/200 V/400 V
23-bit Absolute/Incremental encoder with battery-less option
High frequency response: 3.2 kHz

Technical Specifications

Series	MSMF Series
Protection Class	IP65 (excluding rotating portion of output shaft and leadwire end)
Flange Size	80 mm square
Rated Output	750 W
Rated Voltage	200 V
Rated Current	4.1 A rms (reference value)
Rated Torque	2.39 N⋅m
Continuous Stall Torque	2.39 N⋅m
Max. Peak Torque	7.16 N⋅m
Max. Current	17.4 A 0-p (reference value)
Rated Speed	3000 r/min
Max. Speed	6000 r/min
Rotor Inertia	1.06 × 10⁻⁴ kg⋅m²
Recommended Inertia Ratio	20 times or less
Encoder	23-bit Absolute/Incremental system (8,388,608 resolution)
Holding Brake	Included
Oil Seal	Included
Shaft Configuration	Key-way with center tap
Mass	3.1 kg

Special Order Notice: Please avoid distributing this motor, or equipment containing this motor, to Japan or other regions through Japan.

Brake Specifications

Static Friction Torque	2.45 N⋅m or more
Engaging Time	70 ms or less
Releasing Time	20 ms or less
Exciting Current	0.42 A DC
Releasing Voltage	1 V DC or more
Exciting Voltage	24 ± 1.2 V DC

Important Brake Information: This brake releases when energized. Do not use for braking the motor in motion. Refer to the instruction manual for detailed specifications and usage notes.

Permissible Load Specifications

During Assembly - Radial Load (P-direction)	686 N
During Assembly - Thrust Load (A-direction)	294 N
During Assembly - Thrust Load (B-direction)	392 N
During Operation - Radial Load (P-direction)	392 N
During Operation - Thrust Load (A,B-direction)	147 N

Compatible Drivers

Part Number	Series	Type	Interface	Frame	Supply Voltage
MCDLN35NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	C-Frame	Single/3-phase 200 V
MCDLN35SE	A6SE series	Position control type	Pulse train only	C-Frame	Single/3-phase 200 V
MCDLN35SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485/RS232)	C-Frame	Single/3-phase 200 V
MCDLT35NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	C-Frame	Single/3-phase 200 V
MCDLT35SF	A6SF series	Multifunction type	Analog/Pulse, Modbus (RS485/RS232)	C-Frame	Single/3-phase 200 V

Product Improvement Notice: Specifications and design of the products are subject to change without notice for product improvement.

Torque Characteristics

Specifications and design of the products are subject to change without notice for product improvement.
