MHMF202L1G6M Panasonic 2KW AC Servo Motor

Large Image : MHMF202L1G6M Panasonic 2KW AC Servo Motor

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MHMF202L1G6M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	100pcs/month
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MHMF202L1G6M Panasonic 2KW AC Servo Motor

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 2KW AC servo motor , Panasonic servo motor with driver , 2KW AC motor with warranty

MHMF202L1G6M Panasonic 2KW AC Servo Motor

High-performance AC servo motor from Panasonic's MINAS A6 family, designed for industrial automation applications requiring precision motion control.

Product Overview

Part Number	MHMF202L1G6M
Product Type	Servo Motor
Family Name	MINAS A6
Series	MHMF Series
Motor Type	High inertia, Connector type

Key Features

Power range: 50 W to 22 kW
Input power supply for Driver: DC 24 V/48 V or AC 100 V/200 V/400 V
23-bit Absolute/Incremental encoder system
Battery-less Absolute/Incremental encoder
High frequency response: 3.2 kHz
Protection class: IP67 (excluding rotating shaft and connector pins)

Technical Specifications

Flange Size	176 mm sq.
Rated Output	2000 W
Rated Voltage	200 V
Rated Current	12.5 A rms (reference value)
Rated Torque	9.55 N⋅m
Continuous Stall Torque	11.5 N⋅m
Maximum Peak Torque	28.6 N⋅m
Maximum Current	53 A 0-p (reference value)
Rated Rotational Speed	2000 r/min
Maximum Rotational Speed	3000 r/min
Rotor Inertia	55.7 × 10⁻⁴ kg⋅m²
Recommended Inertia Ratio	5 times or less
Mass	11.3 kg
Shaft Configuration	Key-way
Oil Seal	Included
Holding Brake	Not included

Encoder Specifications

Encoder Type	23-bit Absolute/Incremental system
Resolution	8,388,608
Motor Connector	JL10
Encoder Connector	Large size JL10

Important Notice: When using the rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder.

Permissible Load

During Assembly: Radial Load (P-direction)	1666 N
During Assembly: Thrust Load (A-direction)	784 N
During Assembly: Thrust Load (B-direction)	980 N
During Operation: Radial Load (P-direction)	784 N
During Operation: Thrust Load (A, B-direction)	343 N

Applicable Drivers

Part Number	Series	Type	Interface	Frame	Supply Voltage
MEDLN83NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	E-Frame	3-phase 200 V
MEDLN83SE	A6SE series	Position control type	Pulse train only	E-Frame	3-phase 200 V
MEDLN83SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485 /RS232)	E-Frame	3-phase 200 V
MEDLT83NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	E-Frame	3-phase 200 V
MEDLT83SF	A6SF series	Multifunction type	Analog /Pulse, Modbus (RS485 /RS232)	E-Frame	3-phase 200 V

Distribution Notice: Please avoid distributing this motor, or equipment containing this motor, to Japan or other regions through Japan.

Product Improvement: Specifications and design of the products are subject to change without notice for product improvement.
