MSMF202L1G6M Panasonic 2KW AC Servo Motor

Large Image : MSMF202L1G6M Panasonic 2KW AC Servo Motor

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MSMF202L1G6M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	100pcs/month

Contact Now Chat Now

MSMF202L1G6M Panasonic 2KW AC Servo Motor

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 2KW AC servo motor , Panasonic servo motor with driver , 2KW AC motor with warranty

MSMF202L1G6M Panasonic 2KW AC Servo Motor

Product Overview

The MSMF202L1G6M is part of Panasonic's MINAS A6 Family, featuring low inertia design and connector-type configuration for industrial automation applications.

Key Features

Power range: 50W to 22kW
Input power supply: DC 24V/48V or AC 100V/200V/400V
23-bit Absolute/Incremental encoder system
Battery-less Absolute/Incremental encoder
High frequency response: 3.2 kHz
IP67 protection rating

Technical Specifications

Part Number	MSMF202L1G6M
Rated Output	2000W
Rated Torque	6.37 N⋅m
Continuous Stall Torque	7.64 N⋅m
Maximum Peak Torque	19.1 N⋅m
Rated Rotational Speed	3000 r/min
Maximum Rotational Speed	5000 r/min
Rated Current	11.3 A rms
Maximum Current	48 A 0-p
Rotor Inertia	4.06 × 10⁻⁴ kg⋅m²
Flange Size	100 mm sq.
Mass	5.6 kg
Shaft Type	Key-way
Holding Brake	Without
Oil Seal	With

Encoder Specifications

Encoder Type	23-bit Absolute/Incremental system
Resolution	8,388,608
Motor Connector	JL10
Encoder Connector	Large size JL10

Permissible Load

During Assembly - Radial Load (P-direction)	980 N
During Assembly - Thrust Load (A-direction)	588 N
During Assembly - Thrust Load (B-direction)	686 N
During Operation - Radial Load (P-direction)	490 N
During Operation - Thrust Load (A,B-direction)	196 N

Important Notice: When using the rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder.

Compatible Drivers

Part Number	Series	Type	Interface	Frame	Supply Voltage
MEDLN83NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	E-Frame	3-phase 200V
MEDLN83SE	A6SE series	Position control type	Pulse train only	E-Frame	3-phase 200V
MEDLN83SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485/RS232)	E-Frame	3-phase 200V
MEDLT83NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	E-Frame	3-phase 200V
MEDLT83SF	A6SF series	Multifunction type	Analog/Pulse, Modbus (RS485/RS232)	E-Frame	3-phase 200V

Torque Characteristics

Dotted line represents the torque at 10% less supply voltage.

Dimensions

[Unit: mm]

Product Improvement Notice: Specifications and design of the products are subject to change without notice.
