MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor

MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor
MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor

Large Image :  MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor

Product Details:
Place of Origin: Japan
Brand Name: Panasonic
Model Number: MDMF302L1G6M
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: original package
Delivery Time: 3 working days
Payment Terms: T/T,Western Union
Supply Ability: 100pcs/month
Contact Now Chat Now

MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor

Description
Condition: Original Brand New Warranty: One Year
Shipping Way: DHL FedEx Express Application: Automation Industries, Oil, Gas, Chemical Industries
Certificate: CE ISO TUV
Highlight:

200V Panasonic AC Servo Motor Driver

,

Panasonic AC Servo Motor Driver 3KW

,

MDMF302L1G6M

MDMF302L1G6M 200V Panasonic AC Servo Motor Driver 3KW AC Servo Motor
Product Overview
Part Number MDMF302L1G6M
Product Type Servo Motor
Product Family MINAS A6 Family Servo Motor
Key Features
  • Middle inertia, Connector type
  • Power range: 50 W to 22 kW
  • Input power supply: DC 24 V/48 V, AC 100 V/200 V/400 V
  • 23-bit Absolute/Incremental encoder
  • Frequency response: 3.2 kHz
Technical Specifications
Series MDMF Series
Protection Class IP67
Flange Size 130 mm sq.
Motor Weight 9.3 kg
Rated Output 3000 W
Rated Torque 14.3 N⋅m
Rated Rotational Speed 2000 r/min
Max. Rotational Speed 3000 r/min
Continuous Stall Torque 15.0 N⋅m
Peak Torque 43.0 N⋅m
Rotor Inertia 18.6 × 10⁻⁴ kg⋅m²
Encoder Resolution 8,388,608 (23-bit)
Important Notice: When using a rotary encoder as an incremental system (not using multi-turn data), do not connect a battery for absolute encoder.
Permissible Load Specifications
During Assembly - Radial Load (P-direction) 980 N
During Assembly - Thrust Load (A-direction) 588 N
During Assembly - Thrust Load (B-direction) 686 N
During Operation - Radial Load (P-direction) 784 N
During Operation - Thrust Load (A, B-direction) 343 N
Compatible Drivers
Part Number Series Type Interface Frame Supply Voltage
MFDLNA3NE A6NE series RTEX, Ultra high-speed Network (Basic type) RTEX F-Frame 3-phase 200 V
MFDLNA3SE A6SE series Position control type Pulse train only F-Frame 3-phase 200 V
MFDLNA3SG A6SG series RS485/RS232 Communication type Pulse, Modbus (RS485 /RS232) F-Frame 3-phase 200 V
MFDLTA3NF A6NF series RTEX, Ultra high-speed Network type (Multi type) RTEX F-Frame 3-phase 200 V
MFDLTA3SF A6SF series Multifunction type Analog /Pulse, Modbus (RS485 /RS232) F-Frame 3-phase 200 V
Product Information: Specifications and design of the products are subject to change without notice for product improvement.

Tag:

Panasonic AC Servo Driver,

Panasonic Servo Motor Drive,

3 Phase Servo Motor Driver
