MDMF502L1G6M Panasonic 5KW AC Servo Motor

Large Image : MDMF502L1G6M Panasonic 5KW AC Servo Motor

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDMF502L1G6M

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	100pcs/month

Contact Now Chat Now

MDMF502L1G6M Panasonic 5KW AC Servo Motor

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 5KW AC servo motor , Panasonic servo motor driver , 5KW AC servo motor with warranty

MDMF502L1G6M Panasonic 5KW AC Servo Motor

Product Overview

The MDMF502L1G6M is a high-performance AC servo motor from Panasonic's MINAS A6 family, featuring middle inertia design and connector-type configuration for industrial automation applications.

Key Features

Power range: 50 W to 22 kW
Input power supply for Driver: DC 24 V/48 V or AC 100 V/200 V/400 V
23-bit Absolute/Incremental battery-less encoder
High frequency response: 3.2 kHz
IP67 protection class (excluding rotating shaft and connector pins)

Technical Specifications

Part Number	MDMF502L1G6M
Family Name	MINAS A6
Series	MDMF Series
Type	Middle inertia
Flange Size	176 mm sq.
Motor Lead Configuration	Connector type
Rated Output	5000 W
Rated Torque	23.9 N⋅m
Continuous Stall Torque	26.3 N⋅m
Max. Peak Torque	71.6 N⋅m
Rated Rotational Speed	2000 r/min
Max. Rotational Speed	3000 r/min
Rated Current	23.3 A rms
Max. Current	99 A 0-p
Rotor Inertia	58.2 × 10⁻⁴ kg⋅m²
Mass	15.6 kg
Shaft Type	Key-way
Oil Seal	Included
Holding Brake	Not included

Encoder Specifications

Encoder Type	23-bit Absolute/Incremental system
Resolution	8,388,608
Motor Connector	JL10
Encoder Connector	Large size JL10

Permissible Load Specifications

During Assembly - Radial Load (P-direction)	1666 N
During Assembly - Thrust Load (A-direction)	784 N
During Assembly - Thrust Load (B-direction)	980 N
During Operation - Radial Load (P-direction)	784 N
During Operation - Thrust Load (A, B-direction)	343 N

Compatible Drivers

Part Number	Series	Type	Interface	Frame	Supply Voltage
MFDLNB3NE	A6NE series	RTEX, Ultra high-speed Network (Basic type)	RTEX	F-Frame	3-phase 200 V
MFDLNB3SE	A6SE series	Position control type	Pulse train only	F-Frame	3-phase 200 V
MFDLNB3SG	A6SG series	RS485/RS232 Communication type	Pulse, Modbus (RS485/RS232)	F-Frame	3-phase 200 V
MFDLTB3NF	A6NF series	RTEX, Ultra high-speed Network type (Multi type)	RTEX	F-Frame	3-phase 200 V
MFDLTB3SF	A6SF series	Multifunction type	Analog/Pulse, Modbus (RS485/RS232)	F-Frame	3-phase 200 V

Important Notice: This product is not intended for distribution to Japan or other regions through Japan. Please avoid using this motor or equipment containing this motor in these regions.

Note: Specifications and design of the products are subject to change without notice for product improvement.
