Eaton Crouse-Hinds MTL SD55X Surge Protective Device with 5kA Surge Current, Low Resistance, and IP54 Protection

Large Image : Eaton Crouse-Hinds MTL SD55X Surge Protective Device with 5kA Surge Current, Low Resistance, and IP54 Protection

Product Details:

Place of Origin:	India
Brand Name:	MTL
Model Number:	SD55X

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Eaton Crouse-Hinds MTL SD55X Surge Protective Device with 5kA Surge Current, Low Resistance, and IP54 Protection

Description

Condition:	Original Brand New	Warranty:	One Year
Series:	Eaton Crouse-Hinds Series	Shipping Way:	DHL FedEx Express
Application:	Automation Industries, Oil, Gas, Chemical Industries	Certificate:	CE ISO TUV
Highlight:	MTL surge protective device SD55X , surge protection device with warranty , SD55X surge protector industrial grade

MTL Surge Protective Device SD55X

Eaton Crouse-Hinds series MTL SD surge protector designed for protecting electronic equipment and systems against surges on signal and I/O cabling. Features 38V AC/55V DC nominal voltage, 5kA surge current rating, and low resistance design.

Key Features

5kA nominal discharge surge current (8/20)
Low resistance design for optimal performance
Fast response time: <1ns
Voltage protection level: <90V at 1kV/µS
400mA nominal load current
Compact T-section DIN rail mounting

Electrical Specifications

Nominal Voltage AC	38V
Nominal Voltage DC	55V
Nominal Discharge Surge Current (8/20)	5 kA
Lightning Impulse Current (10/350 µs)	2.8 kA
Nominal Load Current	400mA
Voltage Protection Level	<90V
Series Resistance	2.2Ω/Line
Max. Leakage Current	5µA

Environmental & Safety Ratings

Area Classification	Hazardous/Classified Locations
IECEx/ATEX Hazardous Rating	Zone 2
Ingress Protection (IP) Rating	IP54
Operating Temperature	-40°C to 80°C
Humidity	5-95% RH (non-condensing)
Standards Compliance	IEC/EN 61643-21, NEC/CEC, IECEx/ATEX

Physical Specifications

Dimensions (L x H x W)	99 mm x 101.3 mm x 7 mm
Weight	70 g
Mounting Method	T-section DIN rail
Conductor Cross-section	12 AWG

Application: Ideal for protecting sensitive electronic equipment and control systems in industrial environments against transient voltage surges on signal and I/O cabling.
