Panasonic MDDLN45SE 1.0kW 200V AC Servo Drive with 3.2kHz Frequency Response for High-Speed Automation

Large Image : Panasonic MDDLN45SE 1.0kW 200V AC Servo Drive with 3.2kHz Frequency Response for High-Speed Automation

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDDLN45SE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MDDLN45SE 1.0kW 200V AC Servo Drive with 3.2kHz Frequency Response for High-Speed Automation

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	1KW AC Servo Motor Driver , Panasonic AC Servo Amplifier , MDDLN45SE

MDDLN45SE Panasonic Servo Drive - 1.0kW 1000W, 200V, MINAS A6 Series

Product Overview

The Panasonic MDDLN45SE represents the pinnacle of 1.0kW motion control technology. Part of the cutting-edge MINAS A6 Series, this AC Servo Driver is engineered for the most demanding high-speed automation environments. By doubling the speed response frequency compared to legacy models, the MDDLN45SE enables machines to achieve higher throughput and superior accuracy.

Operating on a 200V-240V input, this D-Frame amplifier is designed to drive 1000W motors (such as the MHMF102 or MDMF102 series). With integrated 23-bit encoder support and advanced vibration suppression, it provides the stability and precision required for the smart factories of tomorrow.

Technical Specifications

Feature	Specification
Model Number	MDDLN45SE
Series	MINAS A6 Series
Rated Output	1.0 kW (1000 W)
Frame Size	D-Frame
Input Voltage	3-Phase 200V - 240V AC
Frequency Response	3.2 kHz (Industry-Leading)
Encoder Support	23-bit (8,388,608 pulses/rev)
Control Mode	Pulse / Analog (Standard)
Safety Standard	SIL3 / PLe (Safe Torque Off)

Key Advantages

Unrivaled 3.2kHz Response Speed

The MINAS A6 series provides a speed response frequency of 3.2kHz, the highest in the industrial automation market. This allows for near-instantaneous command execution and drastically reduces settling times, directly increasing the PPM (Parts Per Minute) of your production line.

High-Resolution 23-bit Positioning

Equipped to handle 23-bit high-resolution serial encoders, the MDDLN45SE offers over 8 million pulses per revolution. This provides sub-micron precision and exceptionally smooth rotation at low speeds, preventing mechanical wear and improving product quality.

Smart Vibration Suppression

The drive features an enhanced "Adaptive Filter" that automatically detects and cancels mechanical resonance. With 5 notch filters available, it can suppress multiple vibration frequencies simultaneously, ensuring stable operation even in machines with complex mechanical structures.

Efficient D-Frame Architecture

The MDDLN45SE utilizes an optimized thermal design that reduces heat generation within the amplifier. This allows for a more compact cabinet layout and extended internal component life compared to older 1kW models.

Primary Industrial Applications

Lithium Battery Manufacturing: High-speed electrode coating and precise winding
Precision CNC Machining: High-torque axes for milling, engraving, and laser cutting
Semiconductor Tools: High-speed wafer handling and automated inspection
Industrial Robotics: Synchronized control for multi-axis robotic arms and gantries
Advanced Packaging: High-speed rotary cutters and synchronized filling systems
