Panasonic MBDLN25NE 400W AC Servo Driver with RTEX Ultra-High-Speed Network and 23-bit High-Resolution Encoder

Large Image : Panasonic MBDLN25NE 400W AC Servo Driver with RTEX Ultra-High-Speed Network and 23-bit High-Resolution Encoder

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Certification:	CE UL ROSH
Model Number:	MBDLN25NE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MBDLN25NE 400W AC Servo Driver with RTEX Ultra-High-Speed Network and 23-bit High-Resolution Encoder

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic MINAS A6N servo driver , AC servo motor driver with warranty , MBDLN25NE servo driver for automation

Panasonic MBDLN25NE 400W Servo Driver AC 200V 12A MINAS A6NE RTEX

Product Overview

The Panasonic MBDLN25NE is a high-performance AC servo driver from the MINAS A6NE series, engineered for precision motion control in industrial automation applications. With a rated output of 400W and a continuous current of 12A, this B-Frame driver delivers reliable and accurate control for single-axis servo systems via RTEX ultra-high-speed network communication.

✅ Product Status: Active (In Production) - This model is currently in active production and not discontinued, making it suitable for new system designs and legacy system maintenance alike.

Key Technical Specifications

Specification	Value
Manufacturer	Panasonic Industrial Automation Sales
Series	MINAS A6NE (RTEX Network Type)
Frame Size	B-Frame
Part Status	Active (In Production)
Type	AC Servo Driver (Module)
Number of Motors Controlled	1
Wattage - Load	400 W
Current - Output	12 A
Voltage - Load	200 V
Voltage - Supply (Main Circuit)	Single/3-phase 200 ~ 240V +10%/-15% 50/60 Hz
Voltage - Supply (Control Circuit)	Single-phase 200 ~ 240V +10%/-15% 50/60 Hz
Frequency Response	3.2 kHz
Encoder Feedback	23-bit absolute encoder (8,388,608 resolution), 7-wire serial
Control Modes	Profile Position (PP), Cyclic Position (CP), Cyclic Velocity (CV), Cyclic Torque (CT)
Communication Interface	RTEX (Real-time Express), USB
I/O - Control Signal Input	8 inputs (parameter-assignable)
I/O - Control Signal Output	3 outputs (parameter-assignable)
I/O - Analog Output	2 outputs (analog monitor)
I/O - Pulse Output	Line driver output for encoder pulses (A/B phase)
Regeneration	No built-in regenerative resistor (external only)
Safety Function	Without
Control Type	Semi-closed control
Mounting Type	Chassis Mount
Operating Temperature	0°C ~ 55°C
Dimensions (W × H × D)	55mm × 150mm × 130mm
Weight	1.0 kg (approx. 2.2 lbs)
RoHS Compliant	Yes (ROHS3 Compliant)

Key Features

RTEX Ultra-High-Speed Network Communication: Equipped with RTEX (Real-time Express) industrial network interface for high-speed, real-time motion control with deterministic communication. Supports cyclic times down to 125μs for demanding multi-axis applications.
23-bit High-Resolution Encoder: Features a 23-bit (8,388,608 resolution) absolute encoder for ultra-fine positioning accuracy and superior motion control precision.
High-Frequency Response: Delivers a 3.2 kHz frequency response for rapid and dynamic motion control, significantly improving system responsiveness.
Multiple Control Modes: Supports multiple RTES-compatible control modes - Profile Position (PP), Cyclic Position (CP), Cyclic Velocity (CV), and Cyclic Torque (CT) - switchable via RTEX communication commands.
Semi-Closed Control: Standard semi-closed control architecture using motor-mounted encoder feedback for reliable and cost-effective positioning.
USB Communication Interface: Includes USB port for easy connection to computers for parameter setting, real-time status monitoring, and firmware updates.
Flexible I/O Configuration: Features 8 parameter-assignable inputs and 3 parameter-assignable outputs, plus 2 analog monitor outputs for real-time status monitoring.
External Regeneration Required: No built-in regenerative resistor - external resistor required for applications with high regenerative energy.
Wide Operating Temperature Range: Reliable operation from 0°C to 55°C, suitable for various industrial environments.

Model Variants - Important Distinction

This driver belongs to the A6NE series (RTEX Network Type, Basic Model). Please verify your required specifications:

Model	Series	Description
MBDLN25NE	A6NE	RTEX Network Type - Basic model, without safety function
MBDLN25NF	A6NF	RTEX Network Type - Model with safety function (STO)
MBDLN25BE	A6BE	EtherCAT Communication Type
MBDLN25SG	A6SG	General Communication Type - Pulse train only, without network
MBDLN25SE	A6SE	General Communication Type - Standard model

Note: The A6NE series is designed for RTEX network control and does not include built-in safety functions. For applications requiring STO (Safe Torque Off), please refer to the MBDLN25NF variant.

Compatible Servo Motors

The MBDLN25NE is designed for use with Panasonic MINAS A6 series servo motors in the 400W power range. Compatible motor series include:

Motor Type	Description
MINAS A6 Series Motors	400W rated, 200V class
Compatible Inertia Classes	Medium Inertia (Standard), Low Inertia (High-speed)

⚠️ Please verify motor compatibility with your existing system before purchasing. The driver supports 23-bit absolute encoder feedback from MINAS A6 series motors.

RTEX Communication Specifications

Item	Specifications
Protocol	RTEX (Real-time Express)
Control Modes	PP, CP, CV, CT (switchable via RTEX command)
Homing Methods	Various methods supported
Synchronization	Distributed Clock (DC)
Supported Cycle Times	125μs, 250μs, 500μs, 1ms, 2ms, 4ms, 8ms, 10ms

Applications

Ideal for precision motion control applications requiring 400W power output with RTEX network communication:

Industrial Automation Systems
CNC Machinery & Machine Tools
Robotics & Pick-and-Place Equipment
Packaging & Labeling Machinery
Material Handling & Conveyor Systems
Assembly Lines
Semiconductor Manufacturing Equipment
Multi-axis Synchronized Motion Systems

Why Choose Our MBDLN25NE?

✅ Active Production Status: Not discontinued - suitable for new system designs
✅ New Original Stock: Factory-sealed units from authorized sources
✅ Fast Global Shipping: DHL, FedEx, UPS options available
✅ Technical Support: Expert assistance for integration and application guidance
✅ Quality Guarantee: Rigorous testing before shipment
✅ RoHS Compliant: Meets EU environmental standards
✅ RTEX Network Ready: Ideal for high-speed multi-axis synchronized applications

Component Replacement Guidelines

For long-term system maintenance, the following standard replacement cycles are recommended by Panasonic:

Component	Standard Replacement Cycle
Smoothing capacitor	Approx. 5 years
Cooling fan	2-3 years (10,000-30,000 hours)
Aluminum electrolytic capacitor (PCB)	Approx. 5 years
Inrush current preventive relay	Approx. 100,000 cycles (depending on operating conditions)
