Panasonic MCDLT35SF 750W 22A 200V AC Servo Driver for MINAS A6SF Series Automation

Large Image : Panasonic MCDLT35SF 750W 22A 200V AC Servo Driver for MINAS A6SF Series Automation

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Certification:	CE UL ROSH
Model Number:	MCDLT35SF

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MCDLT35SF 750W 22A 200V AC Servo Driver for MINAS A6SF Series Automation

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic MINAS A6S servo driver , AC servo motor driver , MCDLT35SF servo driver with warranty

Panasonic MCDLT35SF Servo Driver, 750W 22A 200V AC Single/3-Phase for MINAS A6SF Series

Product Overview

The Panasonic MCDLT35SF is a high-performance AC servo driver from the MINAS A6SF Series, representing the latest generation of Panasonic's industrial motion control technology. Engineered for applications demanding high speed, intelligence, and ease of use, this compact servo driver delivers 750W output power with 22A current capacity, featuring a 3.2 kHz frequency response and 23-bit high-resolution encoder support for exceptional positioning accuracy.

As part of Panasonic's advanced MINAS A6 family, the MCDLT35SF offers seven selectable control modes including position, speed, torque, and full-closed control, providing unmatched flexibility for diverse automation requirements. The C-frame design (65mm width) enables space-saving panel installation while maintaining robust thermal management through an integrated cooling fan.

Key Applications

Pick-and-place machines and multi-axis robots
Semiconductor manufacturing equipment
PCB drilling and routing machines
CNC machine tools and milling machines
Packaging and labeling machinery
Injection molding machines
Factory automation (FA) systems
Medical device manufacturing equipment

Technical Specifications

Brand	Panasonic
Series	MINAS A6SF Series
Product Type	AC Servo Driver (Servo Amplifier)
Part Number	MCDLT35SF
Power Output	750 W
Output Current	22 A
Load Voltage	200 V
Input Power (Main Circuit)	Single/3-phase 200-240V AC (+10%/-15%), 50/60 Hz
Input Power (Control Circuit)	Single-phase 200-240V AC (+10%/-15%), 50/60 Hz
Frequency Response	3.2 kHz
Control / Drive Type	Servo AC
Control Methods	Position, Velocity, Torque, Full-closed (7 modes switchable)
Encoder Feedback	23-bit (8,388,608 resolution) absolute encoder, 7-wire serial
External Scale Feedback	A/B phase, homing signal differential input; Serial communication support
Communication Interfaces	USB, RS-232, RS-485, Modbus-RTU
Safety Function	STO (Safety Torque Off) - standard
Number of Motors Controlled	1
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-20°C to 80°C (-4°F to 176°F)
Dimensions (W × H × D)	65 × 150 × 170 mm
Weight	1.6 kg (approx. 3.5 lbs)
Mounting Type	Chassis Mount / Base Mount
Product Status	Active (In Production)

Key Features

High-Speed 3.2 kHz Frequency Response

With a 3.2 kHz frequency response, the MCDLT35SF delivers exceptional responsiveness, significantly reducing settling time and improving productivity in high-speed pick-and-place, SMT, and packaging applications.

23-Bit High-Resolution Encoder Support

Compatible with Panasonic's 23-bit absolute encoder (8,388,608 resolution), offering ultra-precise position feedback for applications demanding micron-level accuracy. When used as an incremental system, no battery connection is required.

Seven Control Modes

Supports Position, Speed, Torque, Position/Speed, Position/Torque, Speed/Torque, and Full-closed control modes - switchable via parameters for maximum application flexibility.

Built-in Safety Function (STO)

Equipped with Safety Torque Off (STO) as a standard feature, enabling safe integration into machinery requiring functional safety compliance.

Multiple Communication Interfaces

Integrated USB, RS-232, RS-485, and Modbus-RTU interfaces enable easy connection to PLCs, HMIs, and host controllers for parameter configuration, real-time monitoring, and multi-axis networking (up to 31 axes via RS-485).

Real-Time Auto-Tuning

Advanced real-time auto gain tuning automatically adjusts servo gains based on load conditions, simplifying setup and optimizing performance without manual intervention - ideal for varying load applications.

Built-in Regenerative Resistor

Features a built-in regenerative resistor (external resistor also supported), simplifying installation and reducing component count for most applications.

Compact C-Frame Design

The slim 65mm width design allows for high-density panel mounting, reducing cabinet space requirements while maintaining full 750W output capability.

Flexible Power Supply Input

Supports both single-phase and 3-phase 200V AC input, providing installation flexibility across different facility power configurations.

Robust Environmental Protection

Designed for industrial environments with a wide operating temperature range (0°C to 55°C), ensuring reliable operation in demanding conditions.

Compatible Motors

The MCDLT35SF is designed to pair with Panasonic MINAS A6 Series 750W AC servo motors. Compatible motor models include:

Motor Type	Model Number (No Brake)	Model Number (With Brake)	Description
Standard Inertia	MHMF082L1U2M	MHMF082L1V2M	750W, 200V, with/without holding brake
Medium Inertia	MSMF082L1U2M	MSMF082L1V2M	750W, 200V, high torque
