MDDLN55SE Panasonic 1.5KW AC Servo Driver

Large Image : MDDLN55SE Panasonic 1.5KW AC Servo Driver

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDDLN55SE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

MDDLN55SE Panasonic 1.5KW AC Servo Driver

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 1.5KW servo driver , AC servo motor driver , servo driver with warranty

MDDLN55SE Panasonic 1.5KW AC Servo Driver

Product Overview

Part Number	MDDLN55SE
Product	Servo Driver
Series	MINAS A6S Series
Control Type	Position control (Incremental system only, Pulse train only)
Safety Function	Without safety function

Key Features

Swifter, smarter and easier to use
Powered Up compact driver design
High-performance 1.5KW capacity

Technical Specifications

Family Name	MINAS A6
Series	A6SE series
Frame	D-Frame
Frequency Response	3.2 kHz
Supply Voltage	Single/3-phase 200 V
Dimensions (W×H×D)	85 × 150 × 170 mm
Mass	2.1 kg

Basic Specifications

Input Power: Main Circuit	Single/3-phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz
Input Power: Control Circuit	Single phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz
Encoder Feedback	23-bit (8,388,608 resolution) absolute encoder, 7-wire serial
Control Signal Input	General purpose 10 inputs
Control Signal Output	General purpose 6 outputs
Analog Signal Output	2 outputs (Analog monitor: 2 output)
Pulse Signal Input	2 inputs (Photo-coupler input, Line receiver input)
Pulse Signal Output	4 outputs (Line driver: 3 output, open collector: 1 output)
Communication Function	USB interface for parameter setting and status monitoring
Regeneration	Built-in regenerative resistor (external resistor also enabled)
Control Modes	Position control, Internal velocity command, Position/Internal velocity command

Important Note: Since this unit can be used only as an incremental system, do not connect the battery for absolute encoder. Parameter Pr. 0.15 must be set to "1" (factory settings).

Dimensions & Connectors

Specifications and design of the products are subject to change without notice for product improvement.

Dimensions: 85mm (W) × 150mm (H) × 170mm (D)

The air flow direction of the fan is shown on the external dimension of the driver in the catalog.

For complete technical details, dimensional drawings, and connector specifications, please refer to the product catalog and instruction manual.
