Panasonic MINAS A6 Series 1.5kW 40A Servo Drive with 23-bit High-Resolution Encoder

Large Image : Panasonic MINAS A6 Series 1.5kW 40A Servo Drive with 23-bit High-Resolution Encoder

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Certification:	CE UL ROSH
Model Number:	MDDLN55SG

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MINAS A6 Series 1.5kW 40A Servo Drive with 23-bit High-Resolution Encoder

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 1.5KW servo driver , AC servo motor driver , servo driver with warranty

Panasonic MINAS A6 Series MDDLN55SG Servo Drive 1.5kW 40A 200V AC

Product Overview

The Panasonic MDDLN55SG is a high-performance AC servo driver from the MINAS A6SG series, engineered for precision motion control in demanding industrial automation applications. With a rated output of 1.5kW and a peak current of 40A, this D-Frame driver delivers exceptional performance for heavy-duty servo systems.

✅ Product Status: Active (In Production) - This model is currently in active production and not discontinued, making it suitable for new system designs and legacy system maintenance alike.

Technical Specifications

Specification	Value
Manufacturer	Panasonic Industrial Automation Sales
Series	MINAS A6SG (General Communication Type)
Frame Size	D-Frame
Part Status	Active (In Production)
Type	AC Servo Driver (Module)
Number of Motors Controlled	1
Wattage - Load	1500 W (1.5 kW)
Current - Output	40 A
Voltage - Load	200 V
Voltage - Supply (Main Circuit)	Single/3-phase 200 ~ 240V +10%/-15% 50/60 Hz
Voltage - Supply (Control Circuit)	Single-phase 200 ~ 240V +10%/-15% 50/60 Hz
Frequency Response	3.2 kHz
Encoder Feedback	23-bit absolute encoder (8,388,608 resolution), 7-wire serial
Control Modes	Position Control, Internal Velocity Control, Position/Internal Velocity Control
Communication Interfaces	RS-232, RS-485, USB, Modbus-RTU
I/O - Control Signal Input	10 general-purpose inputs (parameter-selectable)
I/O - Control Signal Output	6 general-purpose outputs (parameter-selectable)
I/O - Analog Output	2 outputs (analog monitor)
I/O - Pulse Signal Input	2 inputs (photo-coupler, line receiver)
I/O - Pulse Signal Output	4 outputs (line driver x3, open collector x1)
Regeneration	Built-in regenerative resistor (external also enabled)
Safety Function	Without
Mounting Type	Chassis Mount
Operating Temperature	0°C ~ 55°C
Dimensions (W × H × D)	85mm × 150mm × 170mm
Weight	2.1 kg (approx. 4.6 lbs)
RoHS Compliant	Yes (EU RoHS 2011/65/EU and 2015/863/EU)

Key Features

23-bit High-Resolution Encoder: Features a 23-bit (8,388,608 resolution) absolute encoder for ultra-fine positioning accuracy and superior motion control precision.
High-Frequency Response: Delivers a 3.2 kHz frequency response for rapid and dynamic motion control, significantly improving system responsiveness.
Flexible Control Modes: Supports switching among three control modes - Position Control, Internal Velocity Control, and Position/Internal Velocity Control - to suit diverse application requirements.
Multiple Communication Interfaces: Equipped with USB (for PC parameter setting and monitoring), RS-232 (1:1 communication), RS-485 (1:n communication up to 31 axes), and Modbus-RTU protocols.
Comprehensive I/O Configuration: Features 10 general-purpose inputs and 6 general-purpose outputs with parameter-selectable functions, plus 2 analog monitor outputs for real-time status monitoring.
Robust Pulse Signal I/O: Supports 2 pulse signal inputs (photo-coupler and line receiver) and 4 pulse signal outputs (3 line driver, 1 open collector) for flexible interfacing with host controllers.
Built-in Regeneration: Includes built-in regenerative resistor with the option to connect an external resistor for higher regenerative capacity.
Wide Power Range Compatibility: Part of the MINAS A6 family covering 50W to 22kW, supporting DC 24V/48V and AC 100V/200V/400V voltages.

Compatible Servo Motors

The MDDLN55SG is designed for use with Panasonic MINAS A6 series servo motors in the 1.5kW power range.

Motor Type	Description
MINAS A6 Series Motors	1.5kW rated, 200V class
Compatible Inertia Classes	Medium Inertia (Standard), Low Inertia (High-speed)

⚠️ Note: Please verify motor compatibility with your existing system before purchasing. The driver supports 23-bit absolute encoder feedback from MINAS A6 series motors.

Model Variants

This driver belongs to the A6SG series (General Communication Type). Please verify your required specifications:

Model	Series	Description
MDDLN55SG	A6SG	General Communication Type - Pulse train only, without safety function, RS485/RS232 communication
MDDLN55SF	A6SF	Standard Type - Full-featured model
MDDLN55SE	A6SE	EtherCAT Communication Type

Note: The A6SG series is designed for pulse train control applications and does not include safety functions. For safety applications, please refer to A6SG with safety function variants or other series.

Applications

Ideal for demanding motion control applications requiring 1.5kW power output:

Industrial Automation Systems
CNC Machinery & Machine Tools
Robotics & Pick-and-Place Equipment
Packaging & Labeling Machinery
Material Handling & Conveyor Systems
Assembly Lines
Semiconductor Manufacturing Equipment
