Panasonic MDDLN55NE MINAS A6 Series 1.5kW 200V EtherCAT Servo Drive with 3.2kHz Bandwidth

Large Image : Panasonic MDDLN55NE MINAS A6 Series 1.5kW 200V EtherCAT Servo Drive with 3.2kHz Bandwidth

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDDLN55NE

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Panasonic MDDLN55NE MINAS A6 Series 1.5kW 200V EtherCAT Servo Drive with 3.2kHz Bandwidth

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Panasonic 1.5KW servo driver , AC servo motor driver , servo driver with warranty

Panasonic MDDLN55NE MINAS A6 Series 1.5kW EtherCAT Servo Drive 200V

Product Overview

The Panasonic MDDLN55NE is a state-of-the-art 1.5kW (1500W) AC Servo Driver specifically engineered for high-speed network communication. As a premier model in the MINAS A6 Series, this drive comes equipped with a native EtherCAT interface, providing the ultra-low latency and high-speed synchronization required for modern smart factories and Industry 4.0 applications.

Operating on a 200V-240V input, the MDDLN55NE is a D-Frame powerhouse designed to drive high-torque 1.5kW motors (such as the MHMF152 or MDMF152 series). With its industry-leading 3.2kHz bandwidth, it virtually eliminates mechanical lag, allowing for sub-micron precision even under heavy loads.

Technical Specifications

Essential data for system integrators and automation engineers:

Model Number	MDDLN55NE
Series	MINAS A6 Series
Communication Protocol	EtherCAT (CoE / CiA402)
Rated Output	1.5 kW (1500 W)
Frame Size	D-Frame
Input Voltage	3-Phase 200V - 240V AC
Frequency Response	3.2 kHz (Industry Benchmark)
Encoder Support	23-bit (8,388,608 pulses/rev)
Safety Features	STO (Safe Torque Off) SIL3 Compliant

Key Advantages

Ultra-Fast 3.2kHz Speed Response

The MINAS A6 series provides a massive 3.2kHz bandwidth, the highest in the industry. For 1.5kW applications, this means superior control over mechanical resonance and the ability to maintain high precision during rapid acceleration and deceleration cycles.

Seamless EtherCAT Integration

The native EtherCAT interface supports CoE (CAN over EtherCAT) and the CiA402 device profile. This ensures perfect synchronization with leading PLCs and motion controllers, making it ideal for high-speed robotic arms and synchronized multi-axis gantries.

High-Resolution 23-bit Feedback

Processes 23-bit high-resolution encoders, offering over 8 million pulses per revolution. This resolution allows for incredibly smooth rotation at low speeds and unmatched positioning accuracy for high-torque industrial applications.

Advanced Vibration Suppression

Equipped with an enhanced adaptive notch filter, the drive automatically detects mechanical vibrations and resonance. It applies corrective filters in real-time, protecting mechanical components and ensuring long-term reliability.

Primary Industrial Applications

Advanced Robotics: High-speed 6-axis industrial robots and delta robots
Lithium Battery Manufacturing: Precise electrode coating and high-speed winding axes
Semiconductor Production: Precision wafer handling and multi-axis vacuum robotics
Large-Scale CNC Machining: High-torque EtherCAT-controlled milling and cutting
Automated Packaging: High-speed synchronized sorting and palletizing systems
