Multifunction Panasonic AC Servo Motor Driver 1.5KW MDDLT55SF

Large Image : Multifunction Panasonic AC Servo Motor Driver 1.5KW MDDLT55SF

Product Details:

Place of Origin:	Japan
Brand Name:	Panasonic
Model Number:	MDDLT55SF

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiable
Packaging Details:	original package
Delivery Time:	3 working days
Payment Terms:	T/T,Western Union
Supply Ability:	500pcs/month

Contact Now Chat Now

Multifunction Panasonic AC Servo Motor Driver 1.5KW MDDLT55SF

Description

Condition:	Original Brand New	Warranty:	One Year
Shipping Way:	DHL FedEx Express	Application:	Automation Industries, Oil, Gas, Chemical Industries
Certificate:	CE ISO TUV
Highlight:	Multifunction Panasonic AC Servo Motor Driver , Panasonic AC Servo Motor Driver MDDLT55SF

Multifunction Panasonic AC Servo Motor Driver 1.5KW MDDLT55SF

Product Overview

The MINAS A6S Series Servo Driver MDDLT55SF delivers enhanced performance with swifter response, smarter control capabilities, and easier operation. This compact, powered-up driver features multifunction control with integrated safety functions.

Part Number	MDDLT55SF
Product Series	A6SF Series
Control Type	Multifunction (Pulse analog full-closed) with safety function
Family Name	MINAS A6
Frame	D-Frame
Frequency Response	3.2 kHz

Technical Specifications

Power Supply

Main Circuit Input	Single/3-phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz
Control Circuit Input	Single phase 200 V (+10% -15%) to 240 V (+10% -15%) 50/60 Hz

Feedback Systems

Encoder Feedback	23-bit (8,388,608 resolution) absolute encoder, 7-wire serial
External Scale Feedback	A/B phase, homing signal differential input. Supports Panasonic Industry communication protocol for servo motor encoders.

I/O Connectivity

Control Signal Input	10 general purpose inputs (function selectable by parameters)
Control Signal Output	6 general purpose outputs (function selectable by parameters)
Analog Signal Input	3 inputs (16-bit A/D: 1 input, 12-bit A/D: 2 inputs)
Analog Signal Output	2 analog monitor outputs
Pulse Signal Input	2 inputs (Photo-coupler input, Line receiver input) - compatible with open collector and line driver interfaces
Pulse Signal Output	4 outputs (Line driver: 3 output, open collector: 1 output) for encoder pulses or external feedback pulses

Communication Interfaces

USB: Interface for computer connection for parameter setting and status monitoring
RS232: 1:1 communication
RS485: 1:n communication (maximum 31 devices)
Modbus-RTU: 1:n communication protocol

Control Modes

Supports switching among 7 control modes: Position control, Speed control, Torque control, Position/speed control, Position/torque control, Speed/torque control, and Full-closed control.

Physical Dimensions

Width	85 mm
Height	150 mm
Depth	170 mm
Mass	2.1 kg

Additional Information

Specifications and design of the products are subject to change without notice for product improvement. For detailed dimensions and connector specifications, please refer to the product catalog. The air flow direction of the fan is indicated on the external dimension diagram in the catalog.

When using as an incremental system (not using multi-turn data), do not connect the battery for absolute encoder. Parameter Pr. 0.15 must be set to "1" (factory settings).
